Sharp 27F543 User Manual

D14 EW CORNER BOTTOM 19-81 (13h-51h) 50 (32h) Offset toward D13. 32
D15NOISE DET LEVEL0-3 (00h-03h)0 (00h)00
D18 V CENTERING 0-63 (00-3Fh) 36 (24h)
D19 V-AGC 0-1 (00h-01h) 0 (00h) 00
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
EX1 FAO VOLUME 0-50 (00h-32h) 36 (24h) 24
EX2 CC-POSITION 0-127 (00h-7Fh) 27 (1Bh) 1C
EX3 INT 0-255 (00h-FFh) 122 (7Ah) Interrupt period adjustment. 7A
EX4 A-ATT 0-127 (00h-7Fh) 90 (5Ah) 5A
EX5 TUNER data 0-3 (00h-03h) 0 (00h) 00
EX6 Think chip-Slice LEVEL 0-255 (00h-FFh) 54 (36h) 12
EX7 RLY DELAY TIME 0-255 (00h-FFh) 0 (00h) For the power control 00
EX8 ADG ON TIME 0-255 (00h-FFh) 10 (0Ah) For the power control 0A
B. SPECIAL SETTING
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
C. OPTION SETTING
OP1OPTION10-255 (00h-FFh)245 (F5h)B5
OP2OPTION20-255 (00h-FFh)188 (BCh)3C
OP3OPTION30-255 (00h-FFh)15 (0Fh)8F
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTESFIXED VALUE
(HEX)
RANGE
D. SOUND ADJUSTMENT
27F543
M01 INPUT LEVEL 0-15 (00h-0Fh) 7 (07h)
M02 MTS VCO 0-63 (00h-3Fh) 38 (26h) 24
M03 FILTER 0-63 (00h-3Fh) 36 (24h) 22
M04 WIDEBAND 0-63 (00h-3Fh) 28 (1Ch)
M05 SPECTRAL 0-63 (00h-3Fh) 23 (17h)
8

Sharp 27F543 Specifications

General

Brand	Sharp
Model	27F543
Category	TV
Language	English
