11
27K-S100/180/300/400
CK27S10/18/30/40
SERVICE
NUMBER
DATA
ADJUSTMENT CONTENTS
ADJUSTMENT ITEM
RANGE
INITIAL VALUE
S01 PICTURE 55 00-7F
S02 TINT 46 00-7F
S03 COLOR 32 00-7F
S04 BRIGHTNESS 40 00-7F
S05 SHARPNESS 24 00-3F
Must be set to "28"=27K-S100/180/300/CK27S10/18/30,
"24"=27K-S400, CK27S40
S06 VERTICAL PHASE 00 00-07 Must be set to "00"
S07 HORIZONTAL PHASE 12 00-1F
S08 RF-AGC 23 00-3F
S09 VERTICAL AMP 20 00-3F
S10 VCO 2C 00-7F
S11 R CUT-OFF 00 00-FF
S12 G CUT -OFF 00 00-FF
S13 B CUT-OFF 00 00-FF
S14 G GAIN 7F 00-FF
S15 B GAIN 7F 00-FF
S16 TRAP(3.58MHz) 00 00 or 01 Must be set to "00"=27K-S100/180/300
Must be set to "01"=27K-S400
S17 BALANCE 20 00-3F Must be set to "20"
S18 C.C.POSITION 17 00-7F
S19 Y-MUTE 00 00,01,03
"00" = NORMAL, "01" = No Y, "03" = No VERTICAL
OP OPTION (Set to each model) 80 00-FF
Must be set to "30"= 27K-S100/CK27S10, "78"= 27K-S300,
"70"= 27K-S180, "7F"= 27K-S400/CK27S40,
"7A"=CK27S30, "72"=CK27S18
M01 MTS LEVEL 0A 00-0F
M02 STEREO-VCO 20 00-3F
M03 FILTER 1C 00-3F
M04 LOW SEPARATION 20 00-3F
M05 HIGH SEPARATION 1B 00-3F
P01 P in P Y-LEVEL 30 00-7F
P02 P in P TINT 29 00-3F Must be set to "27"
P03 P in P COLOR 2E 00-7F
P04 P in P Y-OFFSET 09 00-1F Must be set to "09"
P05 P in P H-POSITION 0A 00-FF Must be set to "0A"
P06 P in P BURST GATE PULSE 00 00-7F Must be set to "00"
P07 P in P FREE RUN 0B 00-0F Must be set to "0B"
Table - B
NECESSARY
UNNECESSARY
ADJUSTMENT
NOTES
PART REPLACED
IC2001
IC2101
X
IC3001
X
CRT
X
IC201 X
X
Data is stored in IC2101.
The adjustment is needed to compensate for characteristics
of parts including IC201 and MTS level (M01).
Holding down both the CH-up/down bottons on the TV set in
the service mode for more than 2 seconds will automatically
write the above initial values into IC2101. Then perform a
complete adjustment.
Adjust items related to picture tube only.
Adjust items related to MTS only (M01~M05).
Holding down both the CH-up/down buttons on the TV set at service mode for more than 2 seconds will automatically
write the above initial values into IC2101.
IC1801
(27K-S300/400
/CK27S30/40)
X
Adjust items related to P-IN-P only (P01~P07).
Only for Models
27K-S300/CK27S30
27K-S400/CK27S40
Table - A
To Next Page
