Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
53
27K-S100/180/300/400
CK27S10/18/30/40
C359 VCKYCY1CB104K J 0.1 16V Ceramic AB
C360 VCEA0A1CW226M J 22 16V EL. AB
C361 VCEA0A1CW477M J 470 16V EL. AC
C362 VCEA0A1CW476M J 47 16V EL. AB
C401 VCKYMN1HB331K J 330p 50V Ceramic AA
C402 VCKYMN1HB101K J 100p 50V Ceramic AA
C403 VCKYCY1CB104K J 0.1 16V Ceramic AB
C404 VCEA0A1HW106M J 10 50V EL. AB
C405 VCEA0A1HW335M J 3.3 50V EL. AB
C406 VCEA0A1HW225M J 2.2 50V EL. AB
C408 VCEA0A1HW106M J 10 50V EL. AB
C409 VCEA0A1HW335M J 3.3 50V EL. AB
C410 RC-QZA104TAYK J 0.1 50V Mylar AB
C411 VCEA0A1CW337M J 330 16V EL. AC
C412 VCKYCY1HB103K J 0.01 50V Ceramic AA
C413 VCKYCY1HB103K J 0.01 50V Ceramic AA
C414 VCKYCY1CB104K J 0.1 16V Ceramic AB
C421 VCCCCY1HH330J J 33p 50V Ceramic AA
C422 VCEA0A1CW476M J 47 16V EL. AB
C451 RC-QZA104TAYK J 0.1 50V Mylar AB
C452 VCEA0A1HW475M J 4.7 50V EL. AB
å C453 VCEA0A2EW226M M 22 250V EL. AD
C454 VCEA0A1CW226M J 22 16V EL. AB
C502 VCEA0A1VW108M J 1000 35V EL. AD
C504 VCKYPA2HB391K J 390p 500V Ceramic AA
C505 RC-QZA473TAYK J 0.047 50V Mylar AB
C507 RC-QZA103TAYK J 0.01 50V Mylar AA
C508 VCEA0A1VW107M J 100 35V EL. AC
C510 VCEA0A1VW108M J 1000 35V EL. AD
C511 VCFYSA1JA473J J 0.047 63V Mylar AC
C512 VCFYSA1JA564J J 0.56 63V Mylar AE
C513 VCEA0A1HW474M J 0.47 50V EL. AB
C514 VCSATA1VE684K J 0.68 35V Tantalum AC
C551 VCSATA1CE225K J 2.2 16V Tantalum AB
C552 VCEA0A1HW225M J 2.2 50V EL. AB
C603 RC-QZA273TAYK J 0.027 50V Mylar AB
C604 VCEA0A1EW227M M 220 25V EL. AA
çå C607 VCFPPD3CA692H M 6900p 1.6kV M-Poly. AC
çå C608 VCFPPD3CA692H M 6900p 1.6kV M-Poly. AC
C612 VCFPPD2DB474J J 0.47 200V M-Poly. AE
C614 VCKYPA2HB331K J 330p 500V Ceramic AA
C631 VCEA0A1HW335M J 3.3 50V EL. AB
C632 RC-QZA103TAYK J 0.01 50V Mylar AA
C633 VCEA0A1HW105M J 1 50V EL. AB
C652 VCEA0A1HW106M J 10 50V EL. AB
C653 VCEA0A1HW106M J 10 50V EL. AB
å C701 RC-FZ017SCEZZ J 0.22 AC250V Plastic AD
C702 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C703 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C704 VCKYPA2HB472K J 4700p 500V Ceramic AB
å C705 RC-EZ0722CEZZ M 820 200V EL. AL
or
RC-EZ0685CEZZ J
or
RC-EZ0657CEZZ J
or
RC-EZ0395CEZZ J
PWB-A: DUNTK9509WEK4(27K-S100)
PWB-A: DUNTK9509WEK5(27K-S180)
PWB-A: DUNTK9509WEL0(CK27S10)
PWB-A: DUNTK9509WEL1(CK27S18)
MAIN UNIT (Continued)
å L701 RCiLF0025PEZZ M Coil (27K-S100/180) AE
or
RCiLF0029PEZZ R
or
RCiLF0087PEZZ R
or
RCiLF0235CEZZ R
or
RCiLF0019PEZZ R
or
RCiLF0090CEZZ J AM
å L701 RCiLF0090CEZZ J Coil (CK27S10/18) AM
L2040 RCiLB0159CEZZ M Oscillation Coil AD
TRANSFORMERS
å T601 RTRNZ0168CEZZ J H-Driver AH
çå T602 RTRNF0020MEZZ M H-Out BC
å T701 RTRNP0416CEZZ J Power (27K-S100/180) AV
å T701 RTRNP0516CEZZ J Power (CK27S10/18) AV
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C51 VCEA0A1CW476M J 47 16V EL. AB
C53 VCEA0A1HW105M J 1 50V EL. AB
C54 VCEA0A1HW475M J 4.7 50V EL. AB
C55 VCEA0A1CW108M J 1000 16V EL. AD
C103 VCEA0A1CW228M M 2200 16V EL. AC
C201 VCKYMN1HB102K J 1000p 50V Ceramic AA
C202 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HB102K J 1000p 50V Ceramic AA
C204 VCKYMN1CY103N J 0.01 16V Ceramic AA
C205 VCEA0A1HW474M J 0.47 50V EL. AB
C206 VCEA0A1CW337M J 330 16V EL. AC
C207 VCKYMN1CY103N J 0.01 16V Ceramic AA
C208 VCEA0A1HW474M J 0.47 50V EL. AB
C209 VCKYCY1HB222K J 2200p 50V Ceramic AA
C210 VCKYMN1HB102K J 1000p 50V Ceramic AA
C301 VCCCCY1HH330J J 33p 50V Ceramic AA
C302 VCCCCY1HH151J J 150p 50V Ceramic AA
C303 VCCCCY1HH390J J 39p 50V Ceramic AA
C307 VCCCCY1HH1R5C J 1.5p 50V Ceramic AD
C308 VCKYCY1HB102K J 1000p 50V Ceramic AA
C309 VCEA0A1CW337M J 330 16V EL. AC
C351 VCKYCY1HB392K J 3900p 50V Ceramic AA
C352 VCEA0A1CW107M J 100 16V EL. AC
C353 VCEA0A1CW337M J 330 16V EL. AC
C354 VCKYCY1CB104K J 0.1 16V Ceramic AB
C355 VCEA0A1CW226M J 22 16V EL. AB
C356 VCKYCY1HB392K J 3900p 50V Ceramic AA
C357 VCEA0A1CW107M J 100 16V EL. AC
C358 VCEA0A1CW337M J 330 16V EL. AC
To Next Page
