Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
72
27K-S100/180/300/400
CK27S10/18/30/40
PWB-A: DUNTK9509WEK6 (27K-S400, CK27S40)
MAIN UNIT (Continued)
R3010 VRD-MN2BE392J J 3.9k 1/8W Carbon AA
R3011 VRD-RA2BE102J J 1k 1/8W Carbon AA
R3012 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R3013 VRD-MN2BE104J J 100k 1/8W Carbon AA
R3014 VRD-MN2BE104J J 100k 1/8W Carbon AA
R3017 VRD-RA2BE102J J 1k 1/8W Carbon AA
R3018 VRD-RA2BE102J J 1k 1/8W Carbon AA
R3201 VRS-CY1JF225J J 2.2M 1/16W M-Ox. AA
R3202 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R3203 VRD-RA2BE103J J 10k 1/8W Carbon AA
R3301 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R3302 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R3303 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R3304 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R3305 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R3306 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R3307 VRD-MN2BE103J J 10k 1/8W Carbon AA
R3308 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R3311 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA
R3312 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA
R3313 VRS-CY1JF561J J 560 1/16W M-Ox. AA
R3314 VRS-CY1JF623J J 62k 1/16W M-Ox. AA
R3315 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R3316 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R3317 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R3318 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R3319 VRS-CY1JF432J J 4.3k 1/16W M-Ox. AA
R3320 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R3321 VRS-CY1JF114J J 110k 1/16W M-Ox. AA
R3322 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
SWITCHES
S2501 QSW-K0079GEZZ J Power AB
S2502 QSW-K0079GEZZ J Vol-down AB
S2503 QSW-K0079GEZZ J Vol-up AB
S2504 QSW-K0079GEZZ J CH-down AB
S2505 QSW-K0079GEZZ J CH-up AB
MISCELLANEOUS PARTS
å RY701 RRLYU0036CEZZ J Relay AM
or
RRLYU0038CEZZ J
å F701 QFS-B4023CEZZ J Fuse 4A(125V) AC
or
QFS-B4021GEZZ J
FB601 RBLN-0037CEZZ J Ferrite Bead AB
FB701 RBLN-0037CEZZ J Ferrite Bead AB
FB702 RBLN-0037CEZZ J Ferrite Bead AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
J921 QSOCD0430CEZZ J Socket AE
P602 QPLGN0160FJZZ J Plug 5-pin(K) AD
P651 QPLGN0361CEZZ J Plug 3-pin AB
P701 QPLGN0207CEZZ J Plug 2-pin(M) AA
P702 QPLGN0461CEZZ J Plug 4-pin(YBN) AB
P703 QPLGN0269GEZZ J Plug 2-pin(P) AB
P901 QPLGN0561CEZZ J Plug 5-pin(HA) AB
P902 QPLGN0461CEZZ J Plug 4-pin(S) AB
P903 QPLGN0561CEZZ J Plug 5-pin(GBN) AB
P1701 QPLGZ0810CEZZ J Plug 8-pin AD
P1702 QPLGZ0610CEZZ J Plug 6-pin AB
P1703 QPLGZ0810CEZZ J Plug 8-pin AD
P2401 QPLGN0561CEZZ J Plug 5-pin AB
RMC2601 RRMCU0227CEZZ J Remote Receiver AK
or
RRMCU0224CEZZ J AM
or
RRMCU0216CEZZ J AK
or
RRMCU0232CEZZ J
RDA501 PRDAR0234PEFW R Heat Sink,IC501 AH
RDA604 PRDAR0233PEFW M Heat Sink,Q602 AE
RDA707 PRDAR0026PEFW R Heat Sink,D707 AD
RDA708 PRDAR0026PEFW R Heat Sink,D708 AD
RDA751 PRDAR5072CEFW J Heat Sink,Q751 AC
RDA752 PRDAR5072CEFW J Heat Sink,IC751 AC
TAN921 QTANJ0523CEZZ M AV Terminal AG
LX-BZ3049GEFD J Screw AA
PWB-H: DUNTK9310WEK1
FRONT AV UNIT
J1001 QJAKE0053GEZZ J Jack,Video in AD
J1002 QJAKE0055GEZZ J Jack, Audio in (L) AD
J1003 QJAKE0059GEZZ J Jack, Audio in (R) AC
P1001 QPLGN0541CEZZ J Plug,5-pin (HA) AB
