Sharp 27SC260 User Manual

V01 PICTURE 0-15 (00h-0Fh) 08 (08h)
V02 TINT 0-127 (00h-7Fh) 66 (42h)
V03 COLOR 0-127 (00h-7Fh) 56 (38h)
V05 BRIGHT 0-127 (00h-7Fh) 64 (40h)
V06 R CUT-OFF 64-255 (40h-FFh) 64 (40h)
V07 G CUT-OFF 64-255 (40h-FFh) 64 (40h)
V08 B CUT-OFF 64-255 (40h-FFh) 64 (40h)
V09 G/R DRIVE 0-127 (00h-7Fh) 64 (40h)
V10 B DRIVE 0-127 (00h-7Fh) 64 (40h)
V11 Y-MUTE/V-STOP 0-2 00 (00h) Y-Mute / Horizontal “—” 00
V12 SHARP 0-63 (00h-3Fh) 50 (32h) 32
V13 DC RESTORATION 0-3 (00h-03h) 02 (02h) 02
V14 BLACK STRETCH 0-3 (00h-03h) 02 (02h) 02
V15 ABL START POINT 0-3 (00h-03h) 03 (03h) 03
V16 ABL GAIN 0-3 (00h-03h) 02 (02h) 02
V17 γ POINT 0-3 (00h-03h) 00 (00h) 00
V19 ENERGY SAVE 0-63 (00h-3Fh) 63 (3Fh) Offset 3F
V24 LOW-G 0-255 (00h-FFh) 12 (0Ch) Color Temp. 0C
V25 LOW-B 0-255 (00h-FFh) 241 (F1h) Color Temp. F1
V26 ML-G 0-255 (00h-FFh) 00 (00h) Color Temp. 00
V27 ML-B 0-255 (00h-FFh) 247 (F7h) Color Temp. F7
V28 HIGH-G 0-255 (00h-FFh) 02 (02h) Color Temp. 02
V29 HIGH-B 0-255 (00h-FFh) 08 (08h) Color Temp. 08
V30 WPL 0-1 01 (01h) 01
V31 RGB CONTRAST 0-63 (00h-3Fh) 59 (3Bh) 3B
V34 VSM GAIN 0-3 (00h-03h) 01 (01h) 01
V36 BPF/TOF-INPUT 0-1 00 (00h) External Input 00
V37 CORING 0-1 00 (00h) 00
V38 VSM PHASE 0-1 00 (00h) 00
V39 COLOR γ 0-1 00 (00h) 00
V40 SHARP-INPUT 0-63 (00h-3Fh) 44 (2Ch) External Input 2C
V41 TINT-INPUT 0-127 (00h-7Fh) 62 (3Eh) External Input 3E
V42 PICTURE-COMPONENT 0-15 (00h-0Fh) 6 (06h) Component Input
V43 TINT-COMPONENT 0-127 (00h-7Fh) 62 (3Eh) Component Input 3E
V44 COLOR-COMPONENT 0-127 (00h-7Fh) 72 (48h) Component Input 48
V45 BRIGHT-COMPONENT 0-127 (00h-7Fh) 84 (54h) Component Input
V46 R CUT OFF-COMPONENT 64-255 (40h-FFh) 64 (40h) Component Input
V47 G CUT OFF-COMPONENT 64-255 (40h-FFh) 64 (40h) Component Input
V48 B CUT OFF-COMPONENT 64-255 (40h-FFh) 64 (40h) Component Input
V49 G/R DRIVE-COMPONENT 0-127 (00h-7Fh) 64 (40h) Component Input
V50 B DRIVE-COMPONENT 0-127 (00h-7Fh) 64 (40h) Component Input
V51 SHARP-COMPONENT 0-63 (00h-3Fh) 44 (2Ch) Component Input 2C
V52 TINT-S 0-127 (00h-7Fh) 62 (3Eh) S-Terminal Input 3E
V53 C-TRAP 0-1 (00h-01h) 00 (00h) 00
V59 AUTO FRESH 0-1 (00h-01h) 00 (00h) 00
V60 SHARP P F 0-1 (00h-01h) 01 (01h) 01
V61 CD MATRIX 0-3 (00h-03h) 02 (02h) 02
V62 B-Y ATT 0-1 (00h-01h) 00 (00h) 00
V63 R-Y ATT 0-1 (00h-01h) 00 (00h) 00
V64 CD MATRIX-COMPONENT 0-3 (00h-03h) 00 (00h) Component Input 00
V65 B-Y ATT-COMPONENT 0-1 (00h-01h) 00 (00h) Component Input 00
V66 R-Y ATT-COMPONENT 0-1 (00h-01h) 00 (00h) Component Input 00
V67 BUZZ 0-1 (00h-01h) 01 (01h) 01
V68 RGB ABCL 0-1 (00h-01h) 01 (01h) 01
V69 PICTURE-VCOMP 0-100 (00h-64h) 47 (2Fh) 16:9 Format (Offset) 2F
V70 COLOR-VCOMP 0-100 (00h-64h) 50 (32h) 16:9 Format (Offset) 32
V71 BRIGHT-VCOMP 0-100 (00h-64h) 51 (33h) 16:9 Format (Offset) 33
V72 PICTURE-DTV 0-15 (00h-0Fh) 06 (06h) Digital CH Copy of V01+01h
V73 TINT-DTV 0-127 (00h-7Fh) 62 (3Eh) Digital CH 47
V74 COLOR-DTV 0-127 (00h-7Fh) 72 (48h) Digital CH 60
V75 BRIGHT-DTV 0-127 (00h-7Fh) 84 (54h) Digital CH Copy of V05-01h
V76 R CUT OFF-DTV 64-255 (40h-FFh) 64 (40h) Digital CH Copy of V06
V77 G CUT OFF-DTV 64-255 (40h-FFh) 64 (40h) Digital CH Copy of V07
V78 B CUT OFF-DTV 64-255 (40h-FFh) 64 (40h) Digital CH Copy of V08
V79 G/R DRIVE-DTV 0-127 (00h-7Fh) 64 (40h) Digital CH Copy of V09
V80 B DRIVE-DTV 0-127 (00h-7Fh) 64 (40h) Digital CH Copy of V10
V81 SHARP-DTV 0-63 (00h-3Fh) 44 (2Ch) Digital CH 52
V82 CD MATRIX-DTV 0-3 (00h-03h) 00 (00h) Digital CH 00
V83 B-Y ATT-DTV 0-1 (00h-01h) 00 (00h) Digital CH 00
V84 R-Y ATT-DTV 0-1 (00h-01h) 00 (00h) Digital CH 00
R01 RF-AGC 0-63 (00h-3Fh) 36 (24h)
R03 RF-AGC REF 0-255 (00h-FFh) 170 (AAh) Standard value for the self-adjust. AA
A. VCJ IC ADJUSTMENT
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
FIXED VALUE
(HEX)
RANGE
NOTES
27SC260
7

Sharp 27SC260 Specifications

General

Brand	Sharp
Model	27SC260
Category	TV
Language	English
