PWB-A: DUNTKD571WEA6
MAIN UNIT
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No.  Description Code
R446 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R447 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R448 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R449 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
U
R451 VRS-RG3AB103J+ X 10k 1W M-Ox. AB
R452 VRD-RM2HD563JY X 56K 1/2W Carbon AA
R453 VRD-RM2HD223JY X 22k 1/2W Carbon AA
R454 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R455 VRD-RM2HD224JY X 220k 1/2W Carbon AA
R456 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R460 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R461 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R462 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R463 VRD-RA2EE680JY X 68 1/4W Carbon AA
R464 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R467 VRS-CY1JF123JY X 12k 1/16W M-Ox. AA
R483 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R502 VRN-RA2BK822FY X 8.2k 1/8W M-Film AB
R503 VRS-CY1JF105JY X 1M 1/16W M-Ox. AA
R504 VRS-CY1JF154JY X 150k 1/16W M-Ox. AA
R505 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R510 VRN-RA2BK103FY X 10k 1/8W M-Film AB
R511 VRN-RA2BK222FY X 2.2k 1/8W M-Film AB
R512 VRN-RA2BK272FY X 2.7k 1/8W M-Film AB
R513 VRD-RM2HD1R0JY X 1 1/2W Carbon AA
R517 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R518 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R521 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
U
R523 VRN-RL3DBR82J+ X 0.82 2W M-Film AB
U
R524 VRS-RG3AB391J+ X 390 1W M-Ox. AB
R601 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R603 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
U
R604 VRS-KA3NG332J X 3.3k 1/2W Carbon AD
R605 VRD-RM2HD331JY X 330 1/2W Carbon AA
R606 VRD-RM2HD331JY X 330 1/2W Carbon AA
U
R609 VRS-RG3AB562J+ X 5.6k 1W M-Ox. AB
R610 VRD-RM2HD220JY X 22 1/2W Carbon AA
R612 VRS-CY1JF154JY X 150k 1/16W M-Ox. AA
R613 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R614 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
U
R615 VRS-KA3NG3R3K X 3.3 7W M-Ox. AD
U
R621 VRN-RL3DB1R2J+ X 1.2 2W M-Film AB
U
R622 VRN-RL3ABR18J+ X 0.18 1W M-Film AB
R623 VRN-RL3AB4R7J+ X 4.7 1W M-Film AB
U
R624 VRS-RG3DB332J+ X 3.3k 2W M-Ox. AB
R625 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R627 VRN-RL3ABR47J+ X 0.47 1W M-Film AB
R628 VRN-RL3ABR47J+ X 0.47 1W M-Film AB
R651 VRS-RG2HC270J+ X 27 1/2W M-Ox. AB
R652 VRD-RA2EE103GY X 10k 1/4W Carbon AA
R653 VRD-RA2EE562GY X 5.6k 1/4W Carbon AA
R689 VRD-RM2HD824JY X 820k 1/2W Carbon AA
R690 VRS-RG3LB471J+ X 470 3.0W M-Ox. AB
U
R701 RR-DZ0049CEZZY X 3.9M 1/2W Solid AB
U
R703 VRW-KQ3NC1R2K X 1.2 7W Cement AC
R705 VRN-RL3DBR22J+ X 0.22 2W M-Film AB
R706 VRN-RL3DBR22J+ X 0.22 2W M-Film AB
R707 VRD-RM2HD270JY X 27 1/2W Carbon AA
R708 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R709 VRS-CY1JF393JY X 39k 1/16W M-Ox. AA
R710 VRS-RG2HC103J+ X 10k 1/2W M-Ox. AB
R711 VRS-CY1JF334JY X 330k 1/16W M-Ox. AA
R712 VRD-RM2HD100JY X 10 1/2W Carbon AA
Ref. No. Part No.  Description Code
R713 VRS-RG2HC152J+ X 1.5k 1/2W M-Ox. AB
R714 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R715 VRN-RL2HCR56J+ X 0.56 1/2W M-Film AB
R716 VRD-RM2HD100JY X 10 1/2W Carbon AA
R720 VRD-RA2BE473JY X 47k 1/8W Carbon AA
R721 VRD-RM2HD332JY X 3.3k 1/2W Carbon AA
R724 VRD-RM2HD101JY X 100 1/2W Carbon AA
R725 VRD-RM2HD222JY X 2.2k 1/2W Carbon AA
R726 VRD-RM2HD222JY X 2.2k 1/2W Carbon AA
R734 VRD-RM2HD124JY X 120k 1/2W Carbon AA
R737 VRN-RL3LB2R2J+ X 2.2 3W M-Film AC
R742 VRD-RA2BE222JY X 2.2k 1/8W Carbon AA
R743 VRD-RM2HD470JY X 47 1/2W Carbon AA
R744 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R745 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R750 VRS-CY1JF224JY X 220k 1/16W M-Ox. AA
R751 VRD-RA2BE473JY X 47k 1/8W Carbon AA
R752 VRD-RA2BE392JY X 3.9k 1/8W Carbon AA
R753 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R754 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R755 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R756 VRD-RA2BE152JY X 1.5k 1/8W Carbon AA
R757 VRN-RL3DB4R7J+ X 4.7 2W M-Film AB
R759 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R761 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R762 VRD-RA2EE151JY X 150 1/4W Carbon AA
R764 VRD-RM2HD562JY X 5.6k 1/2W Carbon AA
R767 VRD-RM2HD151JY X 150 1/2W Carbon AA
R768 VRD-RA2BE393JY X 39k 1/8W Carbon AA
R775 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R776 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R778 VRS-RG3AB271J+ X 270 1W M-Ox. AB
R781 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
R783 VRD-RM2HD681JY X 680 1/2W Carbon AA
R801 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R802 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R803 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R805 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R806 VRS-CY1JF681JY X 680 1/16W M-Ox. AA
R807 VRS-CY1JF681JY X 680 1/16W M-Ox. AA
R808 VRS-CY1JF681JY X 680 1/16W M-Ox. AA
R810 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R903 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R904 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R905 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R906 VRD-RA2BE332JY X 3.3k 1/8W Carbon AA
R907 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R908 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R910 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R911 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R912 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R913 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R914 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R915 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R916 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R917 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R918 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R922 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R923 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R924 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R925 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R926 VRS-CY1JF680JY X 68 1/16W M-Ox. AA
R927 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R929 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R930 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R931 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R932 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R933 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R934 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
27SC26B
31
