Ref. No.Part No.★DescriptionCodeRef. No.Part No.★DescriptionCode
26
32C530
PWB-A: DUNTKB567WEZ5
MAIN UNIT(Continued)
'åD651VHD1SS244//-1∗X1SS244AB
'åD652RH-EX0641GEZZ∗XZener Diode, 12VAB
'åD653VHD1SS119//-1∗X1SS119AB
'åD654VHD1SS119//-1∗X1SS119AB
åD701RH-DX0477CEZZXDiodeAE
D707VHD1SS244//-1∗X1SS244AB
D708VHD1SS244//-1∗X1SS244AB
åD709RH-DXA006WJZZXDiodeAB
D712RH-DX0468CEZZXDiodeAB
D725RH-DX0302CEZZ∗XDiodeAB
D726RH-DX0461CEZZXDiodeAB
D751VHD1SS119//-1∗X1SS119AA
D752VHD1SS119//-1∗X1SS119AA
D753VHD1SS119//-1∗X1SS119AA
D754VHD1SS119//-1∗X1SS119AA
D755VHD1SS119//-1∗X1SS119AA
D756VHD1SS119//-1∗X1SS119AA
D757RH-EX0619GEZZ∗XZener Diode, 6.2VAB
D904RH-EX0631GEZZ∗XZener Diode, 9.1VAB
D905RH-EX0631GEZZ∗XZener Diode, 9.1VAB
D906RH-EX0631GEZZ∗XZener Diode, 9.1VAB
D907RH-EX0631GEZZ∗XZener Diode, 9.1VAB
D908RH-EX0631GEZZ∗XZener Diode, 9.1VAB
D909RH-EX0631GEZZ∗XZener Diode, 9.1VAB
D2040RH-EX0619GEZZ∗XZener Diode, 6.2VAB
D2060RH-EX0619GEZZ∗XZener Diode, 6.2VAB
PACKAGED CIRCUITS
TH501RH-HZ0004GEZZ+XThermistorAB
åVA701RH-VXA009WJZZXVaristorAB
åPR701RMPTP0092CEZZXPackaged CircuitAD
X801RCRSAA010WJZZXCrystalAC
FILTERS AND COILS
CF302RFiLC0449CEZZ+XFilterAB
CF401RFiLC0446CEZZ+XFilterAB
L51VP-CF100K0000∗X Peaking, 10µΗ AB
L201VP-XF1R2K0000∗XPeaking, 1.2µH AB
L203VP-XF100K0000∗XPeaking, 10µΗ AB
L204VP-XF100K0000∗XPeaking, 10µH AB
L231VP-XF680K0000∗XPeaking, 68µH AB
L301VP-XF8R2K0000∗XPeaking, 8.2µH AB
L401VP-XF100K0000∗XPeaking, 10µH AB
L672RCILZ1027CEZZ XCoil AD
L701 RCiLF0345CEZZ X Coil AD
L705RCILP0179CEZZ+ XCoilAB
L728RCiLP0179CEZZ+XCoilAB
L729RCiLP0179CEZZ+XCoilAB
L801VP-XF100K0000∗XPeaking, 10µΗ AB
L802VP-XF100K0000∗XPeaking, 10µΗ AB
L2040RCiLBA003WJZZXOscillation CoilAB
SF201RFiLC0405CEZZXFilterAD
TRANSFORMERS
åT601RTRNZ0057PEZZXTransformerAD
'åT602RTRNFA038WJZZXH-Volt TransformerAU
åT702RTRNWA071WJZZXTransformerAG
CAPACITORS
C53VCEA0A1HW105M+X150VElectrolyticAB
C54VCEA0A1HW475M+X4.750VElectrolyticAB
C55VCEA0A0JW108M+X10006.3VElectrolyticAB
C58VCKYCY1HF103Z∗X0.0150VCeramicAA
C59VCKYPA1HF103Z+X0.0150VCeramicAA
C101VCEA0A0JW108M+X10006.3VElectrolyticAB
C103VCEA0A1CW108M+X100016VElectrolyticAB
C201VCKYCY1HB102K∗X1000p50VCeramicAA
C202VCKYCY1HB103K∗X0.0150VCeramicAA
C203VCKYCY1HB102K∗X1000p50VCeramicAA
C223VCKYCY1CF104Z∗X0.116VCeramicAA
C224VCEA0A1HW474M+X0.4750VElectrolyticAB
C229VCEA0A1CW477M+X47016VElectrolyticAB
C231VCEA0A1EW476M+X4725VElectrolyticAB
C232VCKYCY1HB222K∗X2200p50VCeramicAA
C233VCEA0A1HW474M+X0.4750VElectrolyticAB
C234VCKYCY1HB103K∗X0.0150VCeramicAA
C235VCEA0A1HW106M+X1050VElectrolyticAB
C251VCKYCY1CF104Z∗X0.116VCeramicAA
C252VCEA0A1EW476M+X4725VElectrolyticAB
C302VCCCCY1HH151J∗X150p50VCeramicAA
C303VCCCCY1HH330J∗X33p50VCeramicAA
C304VCEA0A1HW475M+X4.750VElectrolyticAB
C306VCCCCY1HH330J∗X33p50VCeramicAA
C307VCKYCY1CF104Z∗X0.116VCeramicAA
C312VCEA0A1EW476M+X4725VElectrolyticAB
C360VCEA0A1HW475M+X4.750VElectrolyticAB
C361VCEA0A1HW105M+X150VElectrolyticAB
C362VCKYCY1EB223K∗X0.02225VCeramicAA
C363VCKYCY1EB223K∗X0.02225VCeramicAA
C364VCEA0A1EW227M+X22025VElectrolyticAB
C365VCEA0A1HW105M+X150VElectrolyticAB
C366VCEA0A1HW106M+X1050VElectrolyticAB
C367VCEA0A1VW108M+X100035VElectrolyticAB
C368VCKYPA1HF103Z+X0.0150VCeramicAA
C369VCEA0A1CW227M+X22016VElectrolyticAB
C370VCEA0A1CW227M+X22016VElectrolyticAB
C371VCEA0A1EW108M+X100025VElectrolyticAB
C372VCEA0A1EW108M+X100025VElectrolyticAB
C373VCKYCY1HB103K∗X0.0150VCeramicAA
C375VCEA0A1HW475M+X4.750VElectrolyticAB
C401VCEA0A1HW106M+X1050VElectrolyticAB
C402VCEA0A1HW106M+X1050VElectrolyticAB
C403VCKYCY1CF104Z∗X0.116VCeramicAA
C429VCKYCY1HB103K∗X0.0150VCeramicAA
C433VCKYCY1CF104Z∗X0.116VCeramicAA
C434VCKYCY1CF104Z∗X0.116VCeramicAA
C435VCEA0A1HW105M+X150VElectrolyticAB
C436VCKYCY1CF104Z∗X0.116VCeramicAA
C437VCKYCY1CF104Z∗X0.116VCeramicAA
C438VCKYCY1HB103K∗X0.0150VCeramicAA
C439VCEA0A1HW106M+X1050VElectrolyticAB
C440VCFYFA1HA224J+X0.2250VMylarAB
C451VCQYTA2AA104K+X0.1100VMylarAB
C452VCEA0A1EW336M+X3325VElectrolyticAB
C504VCEACA1HC474M+X0.4750VElectrolyticAB
C505VCEA0A1HW474M+X0.4750VElectrolyticAA
C506VCKYCY1HB103K∗X0.0150VCeramicAA
C507VCKYCY1HB103K∗X0.0150VCeramicAA
C510RC-FZ0272CEZZ+X0.39100VMylarAB
C512VCEA0A1EW476M+X4725VElectrolyticAA
C514VCEA0A1VW107M+X10035VElectrolyticAB
C516VCKYCY1HB472K∗X4700p50VCeramicAA
C518VCQYTA2AA473J+X0.047100VMylarAB
C522VCFYFA1HA334J+X0.3350VMylarAB
C523VCEA0A1HW105M+X150VElectrolyticAA
C601VCEA0A1CW477M+X47016VElectrolyticAB
C602VCKYCY1CF104Z∗X0.116VCeramicAA
C603VCEA0A1HW225M+X2.250VElectrolyticAA
C604VCKYCY1EB223K∗X0.02225VCeramicAA
C606VCKYPA2HB561K+X560p500VCeramicAB
C607VCKYPA1HB472K+X4700p50VCeramicAA
C608RC-KZ0033CEZZX150p2kVCeramicAB
'åC609RC-FZ1034CEZZX 13500p 1500VMylarAC
C611VCEA0A1EW477M+X47025VElectrolyticAB
C614VCEA0A1EW108M+X100025VElectrolyticAB
C615VCFYSB2EB823JX0.082250VMylarAB
C617VCEA0A1HW474M+X0.4750VElectrolyticAA
åC622VCKYPA2HB102K+X1000p500VCeramicAB
åC623VCEA4A2EN106M+X10250VElectrolyticAB
C652VCEA0A1HW476M+X4750VElectrolyticAB
C653VCEA0A1HW106M+X1050VElectrolyticAA
C674 VCKYCY1HB391K* X 1000p 500V Ceramic AB
L702 RCiLF0345CEZZ X Coil AD
D673 RH-DXA006WJZZ X Diode AB
D2001 VHD1SS119//-1∗ X 1SS119 AA
L671 RCILZ1005CEZZ X LZ1005CE AD
C225 VCKYCY1CF104Z X 0.1 16V Ceramic AA
C228 VCKYCY1CF104Z X 0.1 16V Ceramic AA
C471 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C227 VCEA0A1HW106M+X 10 50V Electrolyti
c AB
C473 VCCCCY1HH331J* X 330p 50V Ceramic AA
C474 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C475 VCKYCY1CF104Z* X 0.1 16V Ceramic AA
C476 VCKYCY1HB103K X 0.01 50V Ceramic AA
C501 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C616 VCKYPA2HB471K+ X 470p 500V Ceramic AB
