Ref. No.Part No.★DescriptionCodeRef. No.Part No.★DescriptionCode
31
32C530
PWB-C: DUNTKA573WEV0
3-LINE Y/C UNIT
INTEGRATED CIRCUITS
IC1401 VHiTC90A53F-1* X TC90A53F AP
TRANSIST ORS
Q1403 VS2SB709AR/-1* X 2SB709AR AB
Q1406 VS2SB709AR/-1* X 2SB709AR AB
Q1408 VS2SB709AR/-1* X 2SB709AR AB
Q1401 VS2SD601AR/-1* X 2SD601AR AB
Q1402 VS2SD601AR/-1* X 2SD601AR AB
Q1404 VS2SD601AR/-1* X 2SD601AR AB
Q1407 VS2SD601AR/-1* X 2SD601AR AB
COILS
L1401 VP-XF100K0000 * X Peaking 10µH AB
L1402 VP-XF100K0000 * X Peaking 10µH AB
L1406 VP-XF220K0000 * X Peaking 22µH AB
L1407 VP-XF220K0000 * X Peaking 22µH AB
L1408 VP-XF100K0000 * X Peaking 10µH AB
L1410 VP-XF100K0000 * X Peaking 10µH AB
L1414 VP-XF330K0000 * X Peaking 33µH AB
L1417 VP-XF220K0000 * X Peaking 22µH AB
CAPACIT ORS
C1412 VCEA0A1HW106M+ X 10 50V Electrolytic AA
C1413 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1414 VCCCCY1HH3R0C*X 3.0p 50V Ceramic AA
C1415 VCE9GA1CW106M+X 10 16V Elect.(N,P) AB
C1416 VCEA0A1CW477M+X 470 16V Electrolytic AB
C1417 VCKYCY1CF104Z* X 0.1 16V Ceramic AA
C1420 VCCCCY1HH270J* X 27p 50V Ceramic AA
C1421 VCCCCY1HH120J* X 12p 50V Ceramic AA
C1422 VCCCCY1HH120J* X 12p 50V Ceramic AA
C1423 VCCCCY1HH3R0C*X 3.0p 50V Ceramic AA
C1424 VCCCCY1HH270J* X 27p 50V Ceramic AA
C1425 VCCCCY1HH100D* X 10p 50V Ceramic AA
C1428 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1435 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1436 VCKYCY1CF104Z* X 0.1 16V Ceramic AA
C1439 VCE9GA1CW106M+X 10 16V Elect.(N,P) AB
C1440 VCEA0A1HW106M+X 10 50V Electrolytic AA
C1441 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1442 VCFYFA1HA474J+ X 0.47 50V Mylar AB
C1443 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1444 VCKYCY1HB472K* X 4700p 50V Ceramic AA
C1445 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1446 VCCCCY1HH181J* X 180p 50V Ceramic AA
C1447 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1448 VCKYCY1CF104Z* X 0.1 16V Ceramic AA
C1449 VCKYCY1CF104Z* X 0.1 16V Ceramic AA
C1451 VCEA0A1CW107M+X 100 16V Electrolytic AA
C1452 VCKYCY1CF104Z* X 0.1 16V Ceramic AA
C1453 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1454 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1455 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1456 VCKYCY1CF104Z* X 0.1 16V Ceramic AA
C1457 VCEA0A1HW106M+X 10 50V Electrolytic AA
C1458 VCEA0A1HW106M+X 10 50V Electrolytic AA
C1460 VCKYCY1HF103Z* X 0.01 50V Ceramic AA
C1470 VCCCCY1HH270J* X 27p 50V Ceramic AA
C1474 VCCCCY1HH150J* X 15p 50V Ceramic AA
RESISTORS
R1402 VRS-CY1JF000J* X 0 1/16W Metal Oxide AA
R1405 VRS-CY1JF361J* X 360 1/16W Metal Oxide AA
R1406 VRS-CY1JF102J* X 1k 1/16W Metal Oxide AA
R1407 VRS-CY1JF102J* X 1k 1/16W Metal Oxide AA
R1410 VRS-CY1JF473J* X 47k 1/16W Metal Oxide AA
R1411 VRS-CY1JF223J* X 22k 1/16W Metal Oxide AA
R1412 VRS-CY1JF102J* X 1k 1/16W Metal Oxide AA
R1413 VRS-CY1JF122J* X 1.2k 1/16W Metal Oxide AA
R1414 VRS-CY1JF331J* X 330 1/16W Metal Oxide AA
R1415 VRS-CY1JF391J* X 390 1/16W Metal Oxide AA
R1416 VRS-CY1JF102J* X 1k 1/16W Metal Oxide AA
R1421 VRS-CY1JF471F* X 470 1/16W Metal Oxide AA
R1423 VRS-CY1JF152F* X 1.5k 1/16W Metal Oxide AA
R1426 VRS-CY1JF000J* X 0 1/16W Metal Oxide AA
R1428 VRS-CY1JF332J* X 3.3k 1/16W Metal Oxide AA
R1429 VRS-CY1JF222J* X 2.2k 1/16W Metal Oxide AA
R1430 VRS-CY1JF473J* X 47k 1/16W Metal Oxide AA
R1431 VRS-CY1JF223J* X 22k 1/16W Metal Oxide AA
R1432 VRS-CY1JF102J* X 1k 1/16W Metal Oxide AA
R1433 VRS-CY1JF122J* X 1.2k 1/16W Metal Oxide AA
R1434 VRS-CY1JF331J* X 330 1/16W Metal Oxide AA
R1435 VRS-CY1JF102J* X 1k 1/16W Metal Oxide AA
R1436 VRS-CY1JF331J* X 330 1/16W Metal Oxide AA
R1438 VRS-CY1JF222J* X 2.2k 1/16W Metal Oxide AA
R1456 VRS-CY1JF564J* X 560k 1/16W Metal Oxide AA
R1457 VRS-CY1JF103J* X 10k 1/16W Metal Oxide AA
R1458 VRD-RA2BE103J* X 10k 1/8W Carbon AA
R1459 VRS-CY1JF821J* X 820 1/16W Metal Oxide AA
R1466 VRS-CY1JF103J* X 10k 1/16W Metal Oxide AA
R1467 VRS-CY1JF682J* X 6.8k 1/16W Metal Oxide AA
R1473 VRS-CY1JF102J* X 1k 1/16W Metal Oxide AA
R1475 VRS-CY1JF102J* X 1k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB1401RBLN-0061TAZZ* X Ferrite Bead AA
P1401 QPLGZ0810CEZZ X Plug, 8pin AB
