10
32R-S50/S400,
36R-S50/S400,CR32S40
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
RANGE
INITIAL VALUE
S01 PICTURE 5E 00-7F
S02 TINT 46 00-7F
S03 COLOUR 32 00-7F
S04 BRIGHTNESS 40 00-7F
S05 SHARPNESS 28 00-3F Must be set to "24"
S06 Vert. PHASE 00 00-07 Must be set to "00"
S07 Hor. PHASE 12 00-1F
S08 RF AGC 23 00-3F
S09 Vert. AMPLITUDE 20 00-3F
S10 PIF VCO 2C 00-7F
S11 R CUT-OFF 00 00-FF
S12 G CUT -OFF 00 00-FF
S13 B CUT-OFF 00 00-FF
S14 G GAIN 7F 00-FF
S15 B GAIN 7F 00-FF
S16 TRAP 00 00,01 Must be set to "01"
S17 4B 00-3F
S18 CC POSITION 17 00-FF
S19 MUTE 00 00,01,03
"00" : NORMAL, "01" : Y-MUTE, "03" : V-STOP & Y-MUTE
S20 ENERGY SAVE OFFSET 20 00-3F Must be set to "23"
S21 PERIOD ADJ. 7A 00-FF Must be set to "7A"
S22 FAO VOLUME STEP 25 00-32
S23 TUNER 00 00,01 Must be set to "00"
S24 FAV. COLOR RTONE-G F9 00-FF
S25 FAV. COLOR RTONE-B EB 00-FF
S26 FAV. COLOR BTONE-G 02 00-FF
S27 FAV. COLOR BTONE-B 08 00-FF
S28 COLOR TEMP LOW-G E1 00-FF
S29 COLOR TEMP LOW-B AE 00-FF
S30 COLOR TEMP ML-G FA 00-FF
S31 COLOR TEMP ML-B E7 00-FF
S32 COLOR TEMP HIGH-G 08 00-FF
S33 COLOR TEMP HIGH-B 14 00-FF
OP1 OPTION1 00 00-FF Must be set to "B1" for 32R-S50/36R-S50
Must be set to "B7" for 32R-S400/36R-S400/CR32S40
OP2 OPTION2 00 00-FF Must be set to "C7" for 32R-S50/36R-S50
Must be set to "E7" for 32R-S400/36R-S400/CR32S40
M01 INPUT LEVEL 0A 00-0F
M02 ST VCO 20 00-3F
M03 FILTER 1C 00-3F
M04 WIDE BAND 20 00-3F
M05 SPECTRAL 1B 00-3F
P01 PIP Y-LEVEL 30 00-7F
P02 PIP TINT 29 00-3F Must be set to "29" for 32R-S400/36R-S400/CR32S40
P03 PIP COLOR 2E 00-7F
P04 PIP Y-OFFSET 09 00-1F Must be set to "09" for 32R-S400/36R-S400/CR32S40
P05 PIP H-POSITION 0A 00-FF Must be set to "0A" for 32R-S400/36R-S400/CR32S40
P06 PIP BGPM 00 00-0F Must be set to "00" for 32R-S400/36R-S400/CR32S40
P07 PIP FREERUN 0B 00-0F Must be set to "0B" for 32R-S400/36R-S400/CR32S40
NECESSARY UNNECESSARY
ADJUSTMENT
PART REPLACED
IC2001
IC201
X
Data is stored in IC2101.
The adjustment is needed to compensate for characteristics of parts
including IC201 and MTS level (M01).
Holding down both the VOL-up/CH-down buttons on the TV set at service mode for more than 2 seconds will
automatically write the above initial values into IC2101.
Table - A
ADJUSTMENT CONTENTS
NOTES
X
IC2101
IC3001
CRT
IC1801
Holding down both the VOL-up/CH-down buttons on the TV set in the
service mode for more than 2 seconds will automatically write the
above initial values into IC2101. Then perform a complete adjustment.
Adjust items related to picture tube only.
Adjust items related to MTS only (M01~M05).
Adjust items related to P-IN-P only (P01~P07).
Table - B
X
X
X
X
