12
32R-S50/S400,
36R-S50/S400,CR32S40
Vertical-Size and Linearity Adjustments
1. Receive a good local channel.
2. Enter the service mode and select the service
adjustment "S09".
3. While observing the top and bottom of the screen,
adjust "S09" data value to proper vertical size.
4. Using the R502 control adjust for the best linearity.
Vertical Phase Adjustment
1. Enter the service mode and select the service
adjustment "S06".
2. Adjust data value to "00".
Note: This must be set "00" when changed data
retrace line will appear.
Horizontal Position Adjustment
1. Receive a good local channel.
2. Enter the service mode and select the service
adjustment "S07".
3. Adjust "S07" data value so that picture is centered.
Caption Position Adjustment (Horizontal)
1. Receive a good local channel.
2. Enter the service mode and select the service
adjustment "S18".
3. A black text box appears on the screen. (see
Figure
B.
below)
4. Adjust "S18" data value so that text box is positioned
in the center of the screen.
3.58MHz Trap Adjustment
1. Receive a good local channel.
2. Enter the service mode and select the service
adjustment "S16".
3. This is a two position adjustment, "00" is ON, "01" is
OFF.
4. Adjust data value to "01" for normal viewing.
Sharpness and Audio Balance Adjustments
1. Receive a good local channel.
2. Enter the service mode and select the service
adjustments "S05" for sharpness and "S17" for audio
balance.
» Sharpness Adjustment
3. Adjust data value to "24"(center of data range) for
sharpness adjustment.
» Audio Balance Adjustment
4. Adjust data value to "20"(center of data range) for
Audio balance adjustment.
Vertical Center Adjustment
1. Receive a good CATV channel.
2. Adjust the S502 so that the picture is centered.
Side Pincushion Adjustment
1. Receive a good CATV channel or crosshatch pattern
signal.
2. Adjust the R676 so that the outermost line on the
screen is straight.
Horizontal Size Adjustment
1. Receive a good CATV channel or crosshatch pattern
signal.
2. Adjust the R678 so that the best horizontal size.
Energy Save Offset Adjustment
1. Enter the service mode and select the service
adjustment "S20".
2. Adjust data value to "23".
Note : This position is used to preset the level for the
energy save function.
Other Adjustments
1. Enter the service mode.
2. Adjust the following data values as listed below.
Figure B.
SERVICE ADJUST DATA
POSITION ITEM
(Hex)
S05 SHARPNESS 24
S06 V-PHASE 00
S16 TRAP 01
S20 E-SAVE 23
S21 TIMER 7A
S23 TUNER SETUP 00
S22 FAO 25
S28 COL. TEMP. LOW-G E1
S29 COL. TEMP. LOW-B AE
S30 COL. TEMP. ML-G FA
S31 COL. TEMP. ML-B E7
S32 COL. TEMP. ML-B 08
S33 COL. TEMP. HIGH-G 14
SERVICE 32R-S50,
32R-S400, 36R-S400,
POSITION 36R-S50
CR32S40
OP1 B1 B7
OP2 C7 E7
