AH-A07BE-C/09BE-C
AH-A07BE/09BE/12BE
AY-A07BE-C/09BE-C
AY-A07BE/09BE/12BE
REF. NO. PART NO. DESCRIPTION Q'TY CODE
2-14 PCOV-A609JBWZ Control box cover 1 AC
2-15 PCOV-A611JBWZ Control box cover 1 AF
2-16 PCOV-A610JBWZ Terminal cover 1 AE
2-17 VHLGPIU28RR-1 Photo detector unit (IC201) 1 AK
2-18 QFS-GA027JBE0 Fuse 3A 250V 1 AD
2-19 RH-IXA664JBZZ Microcomputer (IC1) 1 AU
2-29 RH-IZA149JBE0
Integrated circuit (IC2)
1AE
2-21 RIC--A022BDE0
Integrated circuit (IC3)
1AE
2-22 RIC--A025BDE0
Integrated circuit(IC4,IC5) [AH-A07BE/A07BE-C/A09BE/A09BE-C/A12BE]
2AE
2-23 VHIBR24C01A-6 E
2
PROM (IC6) 1 AF
2-24 RH-IZA140JBE0 Integrated circuit (IC7) 1 AE
2-25 RH-VZA020JBE0
Varistor (CNR1,CNR2.CNR3)[AY-A07BE/A07BE-C/A09BE/A09BE-C/A12BE]
3AE
2-25 RH-VZA020JBE0
Varistor (CNR3) [AH-A07BE/A07BE-C/A09BE/A09BE-C/A12BE]
1AE
2-26 RRLYDA010JBZZ Relay (RY1) 1 AH
2-27 RTRN-A291JBZZ Transformer 1 AS
2-28 RH-VXA002JBZZ Varistor (NR) 1 AF
2-29 VHRS201D01/-6 Solid state relay (SSR1) 1 AK
2-30 VHPGL6ZE27+-6 LED <GREEN> (LED4 ~ LED7) 4 AG
2-31 VHPGL6ZR27+-6 LED <RED> (LED2) 1 AF
2-32 VHPGL6ZS27+-6 LED <ORANGE> (LED3) 1 AF
CYCLE PARTS
3- 1 CPIPCA678JBKZ Pipe assembly [except for AH-A12BE, AY-A12BE] 1 BG
3- 1 CPIPCA679JBKZ Pipe assembly [AH-A12BE, AY-A12BE] 1 BH
3- 2 PSEN-A004JBK0 Flare nut assembly(1/4") 1 AE
3- 3 PSEN-A005JBK0 Flare nut assembly(3/8")[except for AH-A12BE, AY-A12BE] 1 AG
3- 3 PSEN-A016JBK0 Flare nut assembly (1/2")[AH-A12BE, AY-A12BE] 1 AR
3- 4 PVLV-0341JBE0 Flare union (1/4") 1 AG
3- 5 PVLV-0342JBE0 Flare union (3/8") [except for AH-A12BE, AY-A12BE] 1 AH
3- 5 PVLV-0406JBE0 Flare union (1/2")[AH-A12BE, AY-A12BE] 1 AK
3- 6 DEVA-A121JBKZ Evaporator assembly[AH-A09BE/A09BE-C, AY-A09BE/A09BE-C] 1 BS
3- 6 DEVA-A122JBKZ Evaporator assembly [AH-A12BE, AY-A12BE] 1 BT
3- 6 DEVA-A123JBKZ Evaporator assembly[AH-A07BE/A07BE-C, AY-A07BE/A07BE-C] 1 BR
ACCESSORY PARTS
4- 1 CRMC-A530JBEZ Remote controller[AY-A07BE/A07BE-C/A09BE/A09BE-C/A12BE] 1 AZ
4- 1 CRMC-A531JBEZ Remote controller[AH-A07BE/A07BE-C/A09BE/A09BE-C/A12BE] 1 AZ
4- 2 UBATUA027JBE0 Battery pack 1 AE
4- 3 LHLD-A477JBFA
Cord holder(for covering the terminal board of indoor unit)
1AE
4- 4 XTTSD40P16000 Tapping screw (for fixing the cord holder) 1 AA
4- 5 LX-NZA207JBEZ Special nut (for fixing long screw steadily) 9 AE
4- 6 LPFT-A029JBF0 Drain hose adpter[AY-A07BE/A07BE-C/A09BE/A09BE-C/A12BE] 1 AD
4- 7 PPLTNA058JBWZ Mounting plate 1 AS
4- 8 XTTSD45P30000 Long screw 8 AA
4- 9 TINSEA266JBRZ Operation manual 1 AM
4-10 TINS-A670JBRZ Installation manual 1 AE
4-11 TINS-A671JBRZ Installation manual 1 AE
4-12 LX-BZA106JBE0 Special screw (for hanging remote controller) 1 AE
SCREWS
5- 1 LX-BZA075JBE0 Special screw (for earth) 1 AA
PACKING PARTS
6- 1 CPADBA038JBKZ Packing pad assembly 1 AK
6- 2 SPAKCA750JBEZ Packing case [AH-A07BE] 1 AR
6- 2 SPAKCA976JBEZ Packing case [AH-A07BE-C] 1 AQ
6- 2 SPAKCA749JBEZ Packing case [AH-A09BE] 1 AR
6- 2 SPAKCA975JBEZ Packing case [AH-A09BE-C] 1 AQ
6- 2 SPAKCA751JBEZ Packing case [AH-A12BE] 1 AR
6- 2 SPAKCA974JBEZ Packing case [AY-A07BE-C] 1 AQ
6- 2 SPAKCA746JBEZ Packing case [AY-A09BE] 1 AR
6- 2 SPAKCA973JBEZ Packing case [AY-A09BE-C] 1 AQ
6- 2 SPAKCA748JBEZ Packing case [AY-A12BE] 1 AR
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
To Next Page
