AH-A07BE-C/09BE-C
AH-A07BE/09BE/12BE
AY-A07BE-C/09BE-C
AY-A07BE/09BE/12BE
5
ITEMS
INDOOR UNIT
OUTDOOR UNIT
INDOOR UNIT
OUTDOOR UNIT
INDOOR UNIT
OUTDOOR UNIT
AH-A09BE AU-A09BE AH-A09BE-C AU-A09BE-C AH-A12BE AU-A12BE
Cooling capacity kW 2.64 3.5
Moisture removal Liters/h 0.8 1.2
Electrical data
Phase – Single
Rated frequency Hz 50
Rated voltage range V 198 to 264
Rated voltage V 220 - 240
Rated current A 3.8 - 3.6 5.0 - 4.8
Rated input W 820 - 850 1090 - 1120
Power factor % 98 - 98 99 - 97
Compressor Type Hermetically sealed rotary type
Model QK164PA13A RH154VHST RH207VHET
Oil charge
300cc (SUNISO 4GSI) 300cc (DIAMOND MS56) 520cc (DIAMOND MS56)
Refrigerant system
Evaporator Louver fin and Grooved tube type
Condenser Louver fin and Grooved tube type
Control Capillary tube
Refrigerant volume 550g 560g 870g
Noise level High dB(A) 36 43 36 43 38 48
(at cooling) Med. dB(A) 32 – 32 – 33 –
Low dB(A) 27 – 27 – 29 –
Fan system
Drive Direct drive
Air flow quantity High m
3
/min. 8.6 28 8.6 28 9.3 30.0
Med. m
3
/min. 6.8 – 6.8 – 8.4 –
Low m
3
/min. 5.3 – 5.3 – 7.4 –
Fan
Cross flow fan Propeller fan Cross flow fan Propeller fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4" 1/2", 1/4"
Drain piping mm O.D ø 18
Others
Safety device
Compressor: Overload protector Compressor: Overload protector
(Internal)
Fan motor: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Net dimensions Width mm 815 780 815 780 815 780
Height mm 278 540 278 540 278 540
Depth mm 198 269 198 269 198 269
Net weight kg 9 33 9 33 10 38
Note: The condition of star(
) marked item are 'ISO5151' : 1994(E), condition T1.
