Section 8 Exploded View & Parts List
Parts List
–
Mini Compact Air Conditioners Chassis
–
MS2
8
-
6
Brand
SHARP
MODEL NUMBER
AF
-
S85RX
Compressor
39A1 71AD&5DKB
YZG
-
A071AY2D2
Fan Motor
YSK70
-
4AT(L) /
Weiling
YSK70
-
4AT(L)
/ Broad Ocean
YSK70
-
4AT(L)
/ Weiling
YSK70
-
4AT(L)
/ Broad Ocean
ENG
0
1
2
3
No.
Part name
Qty.
1
Front
panel assembly
1
9JM
201121190218
<
-------------
<
-------------
<
------------
2
Front panel (included in 1)
1
9JM
201121190239
<
-------------
<
-------------
<
------------
3
Filter (included in 1)
1
9JM
201121190216
<
-------------
<
-------------
<
------------
4
Panel frame assembly (included in 1)
1
9JM
201121190208
<
-------------
<
-------------
<
------------
5
Horizontal louver (included in
1)
1
9JM
2011211A0241
<
-------------
<
-------------
<
------------
6
Power cord
1
9JM
202402260120
<
-------------
<
-------------
<
------------
7
Remote controller
1
9JM
203355091093
<
-------------
<
-------------
<
------------
8
Control panel (with overlay)
1
9JM
201121190244
<
-------------
<
-------------
<
------------
9
Display board assembly
1
9JM
201321790071
<
-------------
<
-------------
<
------------
10
Cover for Electr
ic part box
1
9JM
201220290016
<
-------------
<
-------------
<
------------
11
Transformer (included in 12)
1
9JM
202300900136
<
-------------
<
-------------
<
------------
12
Main control board assembly
1
9JM
201321790107
<
-------------
<
-------------
<
------------
13
Evapor
a
t
or temperature sensor
1
9JM
202301300080
<
-------------
<
-------------
<
------------
14
Indoor temperature sensor
1
9
JM
202432390005
<
-------------
<
-------------
<
------------
15
Capacitor clamp
1
9JM
201200100002
<
-------------
<
-------------
<
------------
16
Capacitor
1
9JM
202401400003
<
-------------
9JM
202401400004
<
------------
17
Electric part box
1
9JM
201221190070
<
-------------
<
-------------
<
------------
18
Evaporator assembly
1
9JM
201521390059
<
-------------
9JM
201521390068
<
------------
19
Capillary a
ssembly (include in 18)
1
9JM
201621390223
<
-------------
9JM
201621390261
<
------------
20
Compressor
1
9JM
201402000570
<
-------------
9JM
201402200400
<
------------
21
Overload protector
(include in 20)
1
9JM
201419908013
<
-------------
9JM
201419908012
<
------------
22
Suction pipe
1
9JM
201621390228
<
-------------
N/A
<
------------
23
Disch
arge pipe
1
9JM
201621390255
<
-------------
9JM
201621390259
<
------------
24
Condenser assembly
1
9JM
201521390060
<
-------------
9JM
201521390067
<
------------
25
Bottom fan scroll
1
9JM
202220390009
<
-------------
<
-------------
<
------------
26
Middle fan scroll
1
9JM
202220390008
<
-------------
<
-------------
<
------------
27
Upper fan scroll
1
9JM
202220390007
<
-------------
<
-------------
<
------------
28
Indoor Blower Wheel
1
9JM
201100120002
<
-------------
<
-------------
<
------------
29
Fan motor
1
9JM
202400420445
<
-------------
<
-------------
<
------------
30
Outdoor Axial Fan
1
9JM
201100320614
<
-------------
<
-------------
<
------------
31
Left Support
-
Fan Motor
1
9JM
201221390037
<
-------------
<
-------------
<
------------
32
Right Support
-
Fan Motor
1
9JM
20122139003
8
<
-------------
<
-------------
<
------------
33
Shroud
1
9JM
201121390013
<
-------------
<
-------------
<
------------
34
Window Panel Connector Slides
2
9JM
201121190146
<
-------------
<
-------------
<
------------
35
Cabinet assembly
1
9JM
201221190069
<
-------------
<
-------------
<
------------
36
Top rail
1
9JM
201221190053
<
-------------
<
-------------
<
------------
