Sharp AF-S80RX - Page 49

Section
8
Exploded View & Parts List
Parts List
–
Mini Compact Air Conditioners Chassis
–
MS2
8
-
2
Brand
SHARP
MODEL N
UMBER
AF
-
S60RX
Compressor
YZG
-
A055Y2D2
Fan Motor
YSK33
-
6AS / Weiling
YSK33
-
6AS / Broad Ocean
ENG
0
1
No.
Part name
Qty.
1
Front panel assembly
1
9JM
201121190218
<
-----------------------
2
Front panel (included in 1)
1
9JM
201121190239
<
-----------------------
3
Filter (included in 1)
1
9JM
201121190216
<
-----------------------
4
Panel frame assembly (included in 1)
1
9JM
201121190208
<
-----------------------
5
Horizontal louver (included in 1)
1
9JM
20112 11A0241
<
-----------------------
6
Power cord
1
9JM
202402260119
<
-----------------------
7
Remote controller
1
9JM
203355091093
<
-----------------------
8
Control panel (with overlay)
1
9JM
2
01121190244
<
-----------------------
9
Display board assembly
1
9JM
201321790071
<
-----------------------
10
Cover for Electric part box
1
9JM
201220290016
<
-----------------------
11
Transformer (included in 12)
1
9JM
202300900136
<
-----------------------
12
Main control board assembly
1
9JM
201321790107
<
-----------------------
13
Evaportaor temperature sensor
1
9JM
202301300080
<
-----------------------
14
Indoor temperature sensor
1
9JM
202432390005
<
-----------------------
15
Capacitor clamp
1
9JM
201200100002
<
-----------------------
16
Capacitor
1
9JM
202401400038
<
-----------------------
17
Electric part box
1
9JM
201221190070
<
-----------------------
18
Evaporator assembly
1
9JM
201521190091
<
-----------------------
19
Capillary assemb
ly (include in 18)
1
9JM
201621190271
<
-----------------------
20
Compressor
1
9JM
201402200370
<
-----------------------
21
Overload protector
(include in 20)
1
9JM
201419908021
<
-----------------------
22
Suction pipe
1
9JM
201621190274
<
-----------------------
23
Discharge pipe
1
9JM
201621190313
<
-----------------------
24
Condenser assembly
1
9JM
201521190092
<
-----------------------
25
Bottom fan scroll
1
9JM
202220390009
<
-----------------------
26
Middle fan scroll
1
9JM
202221390002
<
-----------------------
27
Upper fan scroll
1
9JM
202220390007
<
-----------------------
28
Indoor Blower Wheel
1
9JM
201100120002
<
-----------------------
29
Fan motor
1
9JM
202400400826
<
-----------------------
30
Outdoor Axial Fan
1
9JM
201100320614
<
-----------------------
31
Left Support
-
Fan Motor
1
N/A
<
-----------------------
32
Right Support
-
Fan Motor
1
N/A
<
-----------------------
33
Shroud
1
9JM
201121390013
<
-----------------------
34
Window Panel Connector Slides
2
9JM
201121190146
<
-----------------------
35
Cabinet assembly
1
9JM
201221190069
<
-----------------------
36
Top rail
1
9JM
201221190053
<
-----------------------
37
Top Rail Hardwa
re (4 screws)
1
9JM
202821190015
<
-----------------------
