Sharp AF-S85RX - Page 51

Section 8 Exploded View & Parts List
Parts List
–
Mini Compact Air Conditioners Chassis
–
MS2
8
-
4
Brand
SHARP
MODEL NUMBER
AF
-
S80RX
Compre
ssor
39A1 71AD&5DKB
YZG
-
A071AY2D2
Fan Motor
YSK70
-
4AT(L) /
Weiling
YSK70
-
4AT(L)
/ Broad Ocean
YSK70
-
4AT(L)
/ Weiling
YSK70
-
4AT(L)
/ Broad Ocean
ENG
0
1
2
3
No.
Part name
Qty.
1
Front panel assembly
1
9JM
201121190218
<
------------
<
------------
<
-------------
2
Front panel (in
cluded in 1)
1
9JM
201121190239
<
------------
<
------------
<
-------------
3
Filter (included in 1)
1
9JM
201121190216
<
------------
<
------------
<
-------------
4
Panel frame assembly (included in 1)
1
9JM
201121190208
<
------------
<
------------
<
-------------
5
Horizontal louver (included in 1)
1
9JM
2011211A0241
<
------------
<
------------
<
-------------
6
Power cord
1
9JM
202402260120
<
------------
<
------------
<
-------------
7
Remote controller
1
9JM
203355091093
<
------------
<
------------
<
-------------
8
Control panel (with overlay)
1
9JM
201121190244
<
------------
<
------------
<
-------------
9
Display board assembly
1
9JM
201321790071
<
------------
<
------------
<
-------------
10
Cover for Electric part box
1
9JM
201220290016
<
------------
<
------------
<
-------------
11
Transformer (included in
12)
1
9JM
202300900136
<
------------
<
------------
<
-------------
12
Main control board assembly
1
9JM
201321790107
<
------------
<
------------
<
-------------
13
Evaportaor temperature sensor
1
9JM
202301300080
<
------------
<
------------
<
-------------
14
Indoor temperature sensor
1
9JM
202432390005
<
------------
<
------------
<
-------------
15
Capacitor clamp
1
9JM
201200100002
<
------------
<
------------
<
-------------
16
Capacitor
1
9JM
202401400003
<
------------
9JM
202401400004
<
-------------
17
Electric part box
1
9JM
201221190070
<
------------
<
------------
<
-------------
18
Evaporator assembly
1
9JM
201521390059
<
------------
9JM
201521390068
<
-------------
19
Capillary assembly (include in 18)
1
9JM
201621390223
<
------------
9JM
201621390261
<
-------------
20
Compre
ssor
1
9JM
201402000570
<
------------
9JM
201402200400
<
-------------
21
Overload protector
(include in 20)
1
9JM
201419908013
<
------------
9JM
201419908012
<
-------------
22
Suction pipe
1
9JM
201621390228
<
------------
N/A
<
-------------
23
Discharge pipe
1
9JM
201621390255
<
------------
9JM
201621390259
<
-------------
24
Condenser assembly
1
9JM
201521390060
<
------------
9JM
201521390067
<
-------------
25
Bottom fan scroll
1
9JM
202220390009
<
------------
<
------------
<
-------------
26
Middle fan scroll
1
9JM
202220390008
<
------------
<
------------
<
-------------
27
Upper fan scroll
1
9JM
202220390007
<
------------
<
------------
<
-------------
28
Indoor Blower Wheel
1
9JM
201100120002
<
------------
<
------------
<
-------------
29
Fan motor
1
9JM
20240
0420445
<
------------
<
------------
<
-------------
30
Outdoor Axial Fan
1
9JM
201100320614
<
------------
<
------------
<
-------------
31
Left Support
-
Fan Motor
1
9JM
201221390037
<
------------
<
------------
<
-------------
32
Right Support
-
Fan Motor
1
9JM
201221390038
<
------------
<
------------
<
-------------
33
Shroud
1
9JM
201121390013
<
------------
<
------------
<
-------------
34
Window Panel Connector Slides
2
9JM
201121190146
<
------------
<
------------
<
-------------
35
Cabinet assembly
1
9JM
201221190069
<
------------
<
------------
<
-------------
36
Top rail
1
9JM
201221190053
<
------------
<
------------
<
-------------
