Sharp AH-A09BE-C - AY-Series Printed Wiring Diagram

AH-A07BE-C/09BE-C
AH-A07BE/09BE/12BE
AY-A07BE-C/09BE-C
AY-A07BE/09BE/12BE
15
Fig. L-3 Printed Wiring Diagram for AY-A07BE/A07BE-C/A09BE/A09BE-C/A12BE
FROM
TERMINAL
BOARD
(POWER) " 1 "
FROM
TERMINAL
BOARD
(UNIT) " 1 "
FROM
TERMINAL BOARD
(UNIT) " N "
FROM
TERMINAL
BOARD
" 2 "
FROM
TERMINAL BOARD
" 3 "
FROM
THERMISTOR
FROM
LOUVER
(UPPER)
FROM
LOUVER
(LOWER)
INDOOR
FAN MOTOR
(R.P.M. SIGNAL)
INDOOR
FAN MOTOR
