EL-1607PV
– 3 –
2
Packing material & Accessories
3
PWB unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
0GS9202820//// AD D Manual(E/F/S) [AAC]
0GS9202830//// AD D Manual(E/G/F/S/I/N/SW/FI) [ACO]
0GS9202831//// AN N D Manual(E/G/F/S/I/N/SW/FI)Å{Russia) [ACO]
0GS9202990//// AD N D Manual(E/F/S) [ABC]
0GS9203000//// AD N D Manual(E/F/S) [TRC]
2 0GS9183920//// AC D Warning leaflet for battery [ACO]
3
0GS9303280//// AP D Gift box [AAC]
0GS9303290//// AP D Gift box [ACO]
0GS9303550//// AN N D Gift box [ABC,TRC]
4 0GS9411801//// AC D P.E.bag [for AC CORD]
5 0GS9428740//// AP D Pulp mold(L)
6 0GS9428750//// AP D Pulp mold(R)
7 0GS9413720//// AE D P.E.bag (for UNIT)[AAC,ACO]
8 0GS9413830//// AA D P.E.bag (for Manual)[ACO]
9 0GS9413820//// AA D P.E.bag (for BATTERY)[ACO]
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 VCEAGU1HW227M AC C Capacitor(50WV 220µF) [C21]
2 0GS223383700WE AH C Capacitor(3300µF/16V) [C22]
3 VCEAGU1HW106M AB C Capacitor(50WV 10µF) [C16,C19]
4 VCEAGU1HW335M AA C Capacitor(50WV 3.3µF) (ACO)[C20]
5 VCEAGU1HW105M AA C Capacitor(50WV 1.0µF) [C8]
6 VCKYPU1HB103K AA C Capacitor(50WV 0.01µF) [C3,C7,C25]
7 0GS2510467//// AE C Capacitor(0.1µ/50V) [C2,C9,C15,C17,C18,C23]
8 VCKYPU1HB102K AA C Capacitor(50WV 1000pF) [C11,C12,C13,C24,C26]
9 VCKYPU1HB181K AA C Capacitor(50WV 180pF) [C27]
10 VCKYPU1HB101K AA C Capacitor(50WV 100PF) [C10,C14]
11 VCKYPU1HB470K AA C Resistor(47pF/50V) [C4,C5,C6]
12
VRD-HT2EY563J AA C Resistor(1/4W 56KΩ ±5%) [R1,R12]
VRD-HT2EY563J AA C Resistor(1/4W 56KΩ ±5%) (ACO)[R28]
13 VRD-HT2EY682J AA C Resistor(1/4W 6.8KΩ ±5%) [R3]
14 VRD-HT2EY333J AA C Resistor(1/4W 33KΩ ± 5%) [R4]
15 VRD-HT2EY104J AA C Resistor(1/4W 100KΩ ±5%) [R5]
16 VRD-HT2EY104J AA C Resistor(1/4W 100KΩ ±5%) (AAC,ABC,TRC)[R30]
17 VRD-HT2EY1R0J AA C Resistor(1/4W 1Ω ±5%) (AAC,ACO)[R6,R7,R14]
18 VRD-HT2EY102J AA C Resistor(1/4W 1KΩ ±5%) [R8,R9,R10,R11]
19 VRD-HT2EY243J AA C Resistor(1/4W 24KΩ ± 5%) [R13]
20 VRD-HT2EY244J AA C Resistor(1/4W 240KΩ ±5%) [R15,R16,R17]
21 VRD-HT2EY104G AA C Resistor(1/4W 100KΩ ±2%) [R18]
22 VRD-HT2EY204J AA C Resistor(1/4W 200KΩ ±5%) [R19,R31,R32,R33,R34,R35,R36,R37]
23 0GS102256G//// AA C Resistor(1/4W 2.2MΩ,±2%) [R20]
24 VRD-HT2EY472J AA C Resistor(1/4W 4.7KΩ ±5%) [R21]
25 VRD-HT2EY103J AA C Resistor(1/4W 10KΩ ± 5%) (ACO)[R22,R23]
26 VRD-HT2EY362J AA C Resistor(1/4W 3.6KΩ ±5%) [R24]
27 VRD-HT2EY332J AA C Resistor(1/4W 3.3KΩ ±5%) [R25]
28 0GS1901610//// AC C Resistor(1W 1.8kΩ,±5%) [R26]
29 VRD-HT2HY182J AA C Resistor(1/2W 1.8KΩ ±5%) [R27,R29]
30 VRD-HT2HY101J AA C Resistor(1/2W 100Ω ±5%) [R38]
31
VHEHZ5C1///-1 AB B Zener diode(HZ5C1) (AAC,ABC,TRC)[ZD1]
VHEHZ6B1///-1 AB B Zener diode(HZ6B1) (ACO)[ZD1]
32 0GS4151491//// AE B Zener diode(HZ5B1) [ZD2]
33 VHEHZ7A2///-1 AC B Zener diode(HZ7A2) [ZD3]
34 VHD10E1N///-1 AB B Diode(10E1N) [D1,D2,D3,D4,D10,D13]
35
VHDDSS131//-1 AA B Diode(DSS131) [D5,D6,D7,D8,D9]
VHDDSS131//-1 AA B Diode(DSS131) [D17,D18,D20]
VHDDSS131//-1 AA B Diode(DSS131) (ACO)[D11,D12,D14]
36
0GS4140640//// AC B Diode(SD103A) [D19]
0GS4140640//// AC B Diode(SD103A) (ACO)[D15,D16]
37 VS2SA1015-Y-1 AB B Transistor(2SA1015Y) [Q1,Q2]
38 VS2SC3068-/-1 AD B Transistor(2SC3068) [Q3]
39 VS2SD2396JK-1 AE B Transistor(2SD2396) [Q4]
40 VS2SC1815-GRC AB B Transistor(2SC1815-GRC) (ACO)[Q5]
41 0GS1911030//// AD C Resistor(1/8W 10kΩ×4,±5%) [RP1]
42 0GS4151480//// AD B Zener diode(HZ18-3) (TRC)[ZD4,ZD5,ZD6]
(Unit)
901
0GSEL1607P30AA BK E
PWB unit(PWB Unit = Main PWB + all parts except the printer unit,transformer,key PWB and
cables.) [AAC]
0GSEL1607P30AC BK E
PWB unit(PWB Unit = Main PWB + all parts except the printer unit,transformer,key PWB and
cables.) [ACO]
0GSEL1607P30AB BK
N
E
PWB unit(PWB Unit = Main PWB + all parts except the printer unit,transformer,key PWB and
cables.) [ABC]
0GSEL1607P30TR BK
N
E
PWB unit(PWB Unit = Main PWB + all parts except the printer unit,transformer,key PWB and
cables.) [TRC]
