Connections
A
C
D E
F
G
B
* The LAN/Ethernet port is used for Freeview HD services.
EARPHONE
SCART
Input/Outputs for the 40” models only.
CONNECTIONS
EARPHONE Earphone socket
LAN* Network connection
Digital audio Digital optical audio output
SCART SCART input
HDMI 1 (ARC) HDMI input
HDMI 2 HDMI input
RF IN RF/TV Aerial Input
HDMI 3 HDMI input
USB x 2 USB port
CI card in Common interface module
Video Composite Video/CVBS input
YPbPr HD input (Ypbpr)
