Sharp LC-39LD145K User Manual

91
LC-32LD145
LC-39LD145
REF No. PARTS DESCRIPTION *
PRICE
CODE
Q2 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q21 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q22 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q221 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q222 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q225 30076601 TR NMOS DGM6402LDM 5.1A/30V TSOP6 SMD RO G --
Q24 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q26 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q27 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q28 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q29 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q3 30073084 TR NBJT BC848B 0.1A/30V_MB81_SOT23 ROHS G --
Q30 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q31 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q35 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q38 30001458 TR PBJT 0.1A/30V BC858B SOT23 ROHS G --
Q39 30001458 TR PBJT 0.1A/30V BC858B SOT23 ROHS G --
Q4 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q40 30001458 TR PBJT 0.1A/30V BC858B SOT23 ROHS G --
Q41 30001458 TR PBJT 0.1A/30V BC858B SOT23 ROHS G --
Q42 30001458 TR PBJT 0.1A/30V BC858B SOT23 ROHS G --
Q46 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q48 30018060 TR PMOS FDC642P 4A/20V SSOT6 SMD ROHS G --
Q5 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q61 30018060 TR PMOS FDC642P 4A/20V SSOT6 SMD ROHS G --
Q7 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q8 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
Q9 30001457 TR NBJT BC848B 0.1A/30V SOT23 SMD ROHS G --
D12 30038496 DIODE SMD ZEN C2.7V SOD123 ROHS G --
D165 30042066 DIODE SMDSCH1N5819 1A/40V/25A SOD123ROHS G --
D168 30049532 DIODE SMD SCH SK24 2A/40V/50ADO214ACROHS G --
D172 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
D2 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D3 30038493 DIODE SMD ZEN C2.4V SOD123 ROHS G --
D32 30053657 DIODE SMD ARRAY ESD NUP4004M5 TSOP-5RoHS G --
D40 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D5 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
D6 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D60 30019996 DIODE SMD BAV70 215mA/75V 4A SOT23 RoHS G --
D62 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
D63 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
D7 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
D8 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
X3 30068956 XTAL SMD 16MHZ 9PF 10ppm 43Ohm 3225 ROHS G --
X4 30066967 XTAL SMD27MHZ 60R 18pF 30PPM 3225 ROHS G --
X5 30066967 XTAL SMD27MHZ 60R 18pF 30PPM 3225 ROHS G --
F1 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F10 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F11 30000546 RES SMD 1/10W 1.5R J 0805 ROHS G --
COILS AND FILTERS
DIODES
PACKAGED CIRCUITS
REF No. PARTS DESCRIPTION *
PRICE
CODE
F172 30001735 RES SMD 1/8W 0R 1206 ROHS G --
F186 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F187 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F188 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F189 30070980 FERRIT SMD 220R/100Mhz 0.35R M 0.3A 402R G --
F190 30022132 RES SMD 1/16W 0R 0402 ROHS G --
F193 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F194 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F2 30022132 RES SMD 1/16W 0R 0402 ROHS G --
F32 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F33 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F34 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F35 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F47 30070929 TRF SMD BALUN 75R 2X1.2 BW21S7511A01TF R G --
F5 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F60 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F7 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F72 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F73 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F76 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F77 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F80 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F81 30022132 RES SMD 1/16W 0R 0402 ROHS G --
F82 30022132 RES SMD 1/16W 0R 0402 ROHS G --
F83 30022132 RES SMD 1/16W 0R 0402 ROHS G --
F84 30022132 RES SMD 1/16W 0R 0402 ROHS G --
F85 30022132 RES SMD 1/16W 0R 0402 ROHS G --
F87 30022132 RES SMD 1/16W 0R 0402 ROHS G --
F90 30022132 RES SMD 1/16W 0R 0402 ROHS G --
F96 30001734 RES SMD 1/10W 0R 0805 ROHS G --
L1 30020897 COIL SMD 1.8uH 50mA K 0R3 805(SHL)Ro G --
L10 30067047 COIL SMD 390nH 100mA G (603) RoHS G --
L13 30074843 COIL SMD 560nH 10mA J 0R5 402 Ro G --
L18 30075994 COIL SMD 1.2uH 5A M 0R1 6X6X4.5 Ro G --
L2 30072534 COIL SMD 22uH 1.5A M 0R15 6X6X4.5 Ro G --
L27 30074386 COIL SMD 3.3uH 4A4 N 0R17 8x8x4.2 RO G --
L28 30072343 COIL SMD 1uH 2A1 0R39 3X3X1.7 (SHL)Ro G --
L3 30072534 COIL SMD 22uH 1.5A M 0R15 6X6X4.5 Ro G --
L4 30072534 COIL SMD 22uH 1.5A M 0R15 6X6X4.5 Ro G --
L5 30072534 COIL SMD 22uH 1.5A M 0R15 6X6X4.5 Ro G --
L9 30053396 COIL SMD 220nH 0.12A G 2R5 603 Ro G --
C1 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C103 30066876 CAP SMD 4.7UF 10V K X7R (0805) ROHS G --
C104 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C105 30068625 CAP SMD 1.8NF 50V K X7R (0402) ROHS G --
C107 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C108 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C109 30022247 CAP SMD 180PF 50V J (402) ROHS G --
C110 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C1102 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1103 30047294 CAP SMD 4.7UF 10V K X5R (0805) ROHS G --
C1104 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
CAPACITORS
