LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
7 – 29
24 TS_DATA[3] O TS_DATA3
25 VDD supply Power supply (3.3V)
26 GND supply GND
27 VDD_IO_3V3 supply Digital I/O supply (3.3V)
28 TS_DATA[4] O TS_DATA4
29 TS_DATA[5] O TS_DATA5
30 TS_DATA[6] O TS_DATA6
31 TS_DATA[7] O TS_DATA7
32 GPIO4 I/O General-purpose input/output port 4.
33 GPIO3 I/O General-purpose input/output port 3.
34 GPIO2 I/O General-purpose input/output port 2.
35 GPIO1 I/O General-purpose input/output port 1.
36 GPIO0 I/O General-purpose input/output port 0.
37 VDD supply Power supply (3.3V)
38 GND supply GND
39 VDD_IO_3V3 supply Digital I/O supply (3.3V)
40 GNDAS_AD ground GND
41 INM I Negative input for IF and baseband configuration.
42 INP I Positive input for IF and baseband configuration.
43 VCCAISO_D 2.5v Analog ISO neutral polarization. (2.5V)
44 INCM O Internal common mode.
45 REFM O Internal negative reference.
46 REFP O Internal positive reference.
47 GNDA_AD12 ground GND
48 VCCA_AD12 supply Analog supply (2.5V)
49 GNDD_AD12 ground GND
50 VDDD_AD12 1.0v Analog supply (1.0V)
51 GNDA_PLL ground GND
52 VCCA_PLL 2.5v Analog supply (2.5V)
53 GNDD_PLL ground GND
54 VCCD_PLL supply Analog supply (1.0V)
55 ZO MHz Crystal oscillator output.
56 VCCA_OSC 2.5v 2.5V
57 A MHz Crystal oscillator input.
58 GNDA_OSC ground GND
59 VBASE O VBASE
60 VDD10REG I VDD10REG
61 VDD supply Power supply (3.3V)
62 GND supply GND
63 VDD_IO_3V3 supply Digital I/O supply (3.3V)
64 CLK_TST I/O GND
Pin No. Pin Name I/O Pin Function
