1. Languages
Select your preferred on screen display language. This will change the language in
which the menus and associated information is displayed in. When set up has been
completed, this can be changed by selecting Menu > Settings > Language
3. Network setup You can connect the TV to your broadband router or wire-
less network in order to take advantage of the Smart functions. If you connect the
TV to your router using an Ethernet cable (recommended) this step will be skipped.
Follow the on screen prompts to connect to your wireless network. You can set up
the Network connection later in the network menu.
5. TV Installation – Audio.
Depending on how you use / install your TV, select the appropriate setting. The sound
settings on the TV will adjust to suit the type of installation.
6. Default Source
Select the source which you use the most. If Digital TV (Freeview) is chosen, then at
the next step, the set will tune in and default to Digital TV (Freeview). If one of the
other sources is selected, then the set will not tune in at this stage and default to
that input. If it is required to tune the set in later, this can be achieved by selecting
Menu > Channels
4
First time installation
4. Environment of Use
Home Mode: For normal use, by default it is set to a power saving mode which re-
duces the energy used by up to 25% (by reducing the power to the LED/LCD panel).
This can be changed in the picture mode settings.
NOTE: In Home Mode, the TV will switch itself to the standby mode after 4 hours in
the event that the buttons on the remote control or TV set are not used.
Store Mode: For store display use. The picture is adjusted to optimum settings. The
store demonstration will appear on the screen automatically after two minutes.
1 2 3
4 5 6
2. Country Selection
Select the correct fl ag for the country in which the set will be used in. This will enable
the set to correctly install the functions applicable in the country of use.
To obtain a copy of your Operating Instructions, please go to: www.umc-uk.co.uk/instruction-manuals/sharp
Ethernet/LAN* Network connection
Digital Audio Digital Optical Audio Output
USB 2.0 2 x USB port 2.0
HDMI 1 HDMI input
HDMI 2 HDMI input (ARC)
YPbPr HD input (YPbPr)
AV IN Audio/Video input
Mini SCART Mini SCART input
SAT IN Satellite input
RF in RF / TV aerial input
HDMI 3** HDMI input
USB 3.0 USB port 3.0
CI card in Common interface module
SD SD card input
Earphones Earphone input
Setting up the TV set for the rst time
Connectivity
To receive Freeview channels, in particular Freeview
HD channels, you will need a Digital TV aerial and
be in a good Freeview coverage area. You can check
coverage for your postcode at www.freeview.co.uk.
Please note that any Freeview HD channels found
during tuning will be placed in channel positions
above 100.
For example, 101 (BBC1 HD) 102 (BBC2 HD) etc.
* The Ethernet/LAN port is used for Freeview HD services and smart functions.
A
I
M
L
B
J
N
C
D
E
F
G
K
O
H
A
B
C
D
E
F
G
H
I
J
L
K
M
N
O
Fitting the stand
For the stand installation, there is
one type of screw provided as shown
below.
To complete the stand installation you
will require a cross head screw driver.
Place the TV set on a fl at and
clean surface with the panel facing
downwards to avoid damage.
1
1
2
3
Used for attaching the stand
to the TV set ( g.2)
4 x
TV panel must be facing downwards.
Place the TV set on a fl at and clean surface
with the panel facing downwards to avoid
damage.
When the stand feet are installed correctly the
stand feet will be longest at the front of the TV
and shortest at the back with the feet pointing
away from each other.
When the stand/feet are in the correct
position, secure the feet to the underside of
the TV set using 4 screws provided.
Connecting your set
1) Connect the TV to your power socket.
2) If you wish to use the TV to receive Freeview/Saorview
channels, connect the RF input from the TV to your
outdoor Digital TV aerial. If you do not wish to receive
Freeview/Saorview, skip this step.
2
Outdoor Digital
TV Aerial
1.
2.
Register your manufacturers
guarantee online within
14 days of purchase at
www.registertoday.co.uk/sharp
and enter into a prize draw to
win a Sharp Soundbar
4 d
s of
urchase at
www.registertoday.co.uk/shar
nd enter into a
rize draw t
win a Shar
Soundb
Terms and conditions apply. Online registration only.
Back/Shortest
Front/Longest
3 Powering On the TV
Switch on the television by pressing
the TV control stick located on the
TV set.
TV control stick
Insert the batteries supplied into the remote
control. The remote control should automati-
cally be paired with the TV set. If this is not the
case, please refer to the ‘Pairing the remote
control’ section of this Quick Start Guide.
TV Control Stick Remote Control: Installing Batteries
LC-55CUG8052K SHA-QSW-0080.indd 2LC-55CUG8052K SHA-QSW-0080.indd 2 27/03/2019 09:08:2227/03/2019 09:08:22
