PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-MT15/15C/15H/15W/161E/18H
– 3 –
R801 VRS-CY1JB222F J AA 2.2 kohms,1/16W
R802 VRS-CY1JB102J J AA 1 kohm,1/16W
R803 VRS-CY1JB104J J AA 100 kohm,1/16W
R804 VHHMSMDC100-1 J AH Thermistor,Positive/Negative
C,1.0A
R806 VRS-TV2AB102J J AA 1 kohm,1/10W
R807 VRS-CY1JB681F J AA 680 ohms,1/16W
R808 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R809 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R810,811 VRS-CY1JB184F J AA 180 kohms,1/16W
R815 VRS-CY1JB563F J AA 56 kohms,1/16W
R816 VRS-CY1JB243F J AA 24 kohms,1/16W
R821 VRS-CY1JB104J J AA 100 kohm,1/16W
R823 VRS-CY1JB104J J AA 100 kohm,1/16W
R824 VRS-CY1JB153J J AA 15 kohms,1/16W
R826 VRS-CY1JB103J J AA 10 kohm,1/16W
R827 VRS-CY1JB304F J AF 300 kohms,1/16W
R828 VRS-CY1JB224F J AA 220 kohms,1/16W
R829 VRS-CY1JB333J J AA 33 kohms,1/16W
R831 VRS-CY1JB104J J AA 100 kohm,1/16W
R832 VRS-CY1JB106J J AA 10 Mohm,1/16W
R833 VRS-CY1JB470J J AA 47 ohms,1/16W
R851 VRS-CY1JB103J J AA 10 kohm,1/16W
R852 VRS-CY1JB473J J AA 47 kohms,1/16W
R853 VRS-CY1JB101J J AA 100 ohm,1/16W
R871 VRS-CY1JB103J J AA 10 kohm,1/16W
R878 VRS-CY1JB104J J AA 100 kohm,1/16W
R901,902 VRS-CY1JB1R0J J AA 1 ohm,1/16W
R903 VRS-CY1JB331J J AA 330 ohms,1/16W
R904 VRS-CY1JB333J J AA 33 kohms,1/16W
R905 VRS-CY1JB104J J AA 100 kohm,1/16W
R906 VRS-CY1JB274J J AA 270 kohms,1/16W
R907 VRS-CY1JB184J J AA 180 kohms,1/16W
R908 VRS-CY1JB104J J AA 100 kohm,1/16W
R909 VRS-CY1JB103J J AA 10 kohm,1/16W
R920 VRS-CY1JB104J J AA 100 kohm,1/16W
R921 VRS-CY1JB331J J AA 330 ohms,1/16W
R922 VRS-CY1JB104J J AA 100 kohm,1/16W
OTHER CIRCUITRY PARTS
CN101 QCNCW801XAFZZ J AH Socket,22Pin
CN451 QCNCW804NAFZZ J AE Socket,13Pin
CN482 QCNCW804JAFZZ J AE Socket,9Pin
CN601 QCNCW716RAFZZ J AF Socket,16Pin
CN701,702 QCNCWWQ33AFZZ J AE Socket,33Pin
! F871 QFS-L501AAFN0 J AG Fuse,T0.5A L 63V
J701 VHLGP1FB95R-1 J AP Jack,Optical/Line IN
J702 QJAKM0014AWZZ J AF Jack,Mic IN
J703 QJAKM0015AWZZ J AL Jack,Headphones
J801 QJAKC0007AWZZ J AF Jack,DC IN
M901 RMOTV0524AFZZ J AS Motor Ass’y [Spindle]
M902 RMOTV0511AFZZ J AT Motor Ass’y [Sled]
M903 RMOTV0512AFM1 J AR Motor Ass’y [Head Up/Down]
PH901(8-3) VHPGP1S93K/-1 J AF Phote Interrupter,GP1S93K
SW401 QSW-M0172AFZZ J AD Switch,Push Type [Eject]
SW402 QSW-S0948AFZZ J AC Switch,Slide Type [Hold]
SW403 QSW-M0172AFZZ J AD Switch,Push Type
[Disc Lid Open]
SW801 QSW-M0006AWZZ J AD Switch,Push Type
[Ni-MH Battery Detection]
SW902(8-2) QSW-M0170AFZZ J AD Switch,Push Type [Disc Protect]
MECHANICAL PARTS
1 NGERH0597AFZZ J AC Wheel,Drive
2 NSFTD0334AFZZ J AD Screw,Drive
3 LHLDX3141AFM1 J AP Cartridge Holder Ass’y
4 MSPRT1625AFFJ J AD Spring,Eject Lever
5 LANGF1610AFZZ J AC Bracket,Cancel
6 LCHSM0944AFM1 J AT Main Chassis Ass’y
7 PCUSG0599AFZZ J AB Cushion,Mechanism
8 QPWBH0337AFM1 J AN Mechanism Flexible PWB Ass’y
8- 1 ———— — Mechanism Flexible PWB
(Not Replacement Item)
8- 2(SW902) QSW-M0170AFZZ J AD Switch,Push Type [Disc Protect]
8- 3(PH901) VHPGP1S93K/-1 J AF Phote Interrupter,GP1S93K
9 MSPRP0925AFZZ J Spring,Drive Screw
10 PCOVP1339AFZZ J AD Cover,Mechanism
11 MARMM0170AFM1 J AK Magnetic Field Block
12 NGERH0603AFZZ J AE Gear,Drive
! 13 RCTRH8175AFZZ J BM Optical Pickup Unit
[Except for U.S.A.]
! 13 RCTRH8175AF10 J BM Optical Pickup Unit [For U.S.A.]
14 MSPRP0922AFFJ J AD Spring,Drive Grip
15 MSPRP0923AFZZ J Spring,Thrust Plate
16 NSFTM0292AFFW J AC Shaft,Guide
17 MLEVF2641AFZZ J Lever,Eject
18 QPWBH0338AFZZ J AH Magnetic Head Flexible PWB
19 MLEVF2637AFM1 J AH Lift Working Lever Ass’y
20 MLEVF2638AFFW J AD Lever,Block
21 MLEVF2639AFFW J AD Lever,Lift Joint
22 MLEVF2640AFZZ J Lever,Lift
23 MSPRD1362AFFJ J AD Spring,Lift Lever
24 RCILH0112AFZZ J AM Magnetic Head
501 LX-BZ0804AFFF J AA Screw,ø1.4×2.2mm
502 LX-JZ0154AFZZ J AA Screw,ø1.4×2.8mm
503 LX-BZ0823AFZZ J AA Screw,ø1.4×1.2mm
504 LX-WZ9290AFZZ J AA Washer,ø0.8×ø2.4×0.2mm
505 LX-BZ0800AFZZ J AA Screw,ø1.4×2.5mm
506 XSPSN14P01500 J AA Screw,ø1.7×2.5mm
507 LX-JZ0148AFZZ J AA Screw,ø1.7×3mm
508 XWSSD14-05000 J AA Washer,ø1.4×0.5mm
509 LX-BZ0959AFZZ J AB Screw,ø1.4×1.8mm
510 LX-WZ9296AFZZ J AA Washer,ø1.5×ø3.5×0.25mm
511 LX-BZ0974AFZZ J AB Screw,ø1.4×5.5mm
512 LX-BZ0991AFZZ J AB Screw,ø1.2×1.6mm
M901 RMOTV0524AFZZ J AS Motor Ass’y [Spindle]
M902 RMOTV0511AFZZ J AT Motor Ass’y [Sled]
M903 RMOTV0512AFM1 J AR Motor Ass’y [Head Up/Down]
CABINET PARTS
201 GFTAT3006AWM1 J AW Top Cabinet Ass’y [MD-MT15/
15C/15H-S/15W/161E]
201 GFTAT3006AWM2 J AW Top Cabinet Ass’y
[MD-MT15H-RD]
201 GFTAT3006AWM3 J AW Top Cabinet Ass’y [MD-MT18H]
201- 1 ———— — Top Cabinet
(Not Replacement Item)
201- 2 ———— — Bracket,Top Cabinet
(Not Replacement Item)
202 HDECQ0492AWM1 J AP Decoration Plate Ass’y
[MD-MT15/15C/15H-S/15W]
202 HDECQ0492AWM2 J AP Decoration Plate Ass’y
[MD-MT15H-RD]
202 HDECQ0498AWM1 J AP Decoration,Plate Ass’y
[MD-MT161E]
202 HDECQ0499AWM1 J AM Decoration,Plate Ass’y
[MD-MT18H]
202- 1 ———— — Plate,Decoration
(Not Replacement Item)
202- 2 PSHEZ0039AWZZ J Sheet,Decoration Plate
203 TCAUS0044AWZZ J AB Label B,Class 3B
[MD-MT15H/15W/18H Only]
204 PSHEZ0035AWZZ J AB Sheet A,Operation Button
205 PSHEZ0040AWZZ J AB Sheet D,Operation Button
206 PSHEZ0041AWZZ J AB Sheet E,Operation Button
207 JKNBZ0630AWSA J AM Button,Operation
208 LANGT0058AWFW J AG Bracket,Operation Button
209 MSPRP0026AWFW J AB Spring A,Cartridge
210 MSPRP0027AWFW J AC Spring B,Cartridge
211 MSPRP0028AWFW J AB Spring C,Cartridge
212 TCAUS0043AWZZ J AC Label A,Class 3B
[MD-MT15H/15W/18H Only]
213 RUNTK0005AWZZ J AV Key Switch Flexible PWB Ass’y
214 RUNTZ0015AWZZ J BD LCD Ass’y
215 PSHEZ0046AWZZ J AB Sheet E,LCD
216 PSHEZ0044AWZZ J AB Sheet C,LCD
217 PCUSZ0016AWZZ J AB Cushion,Mechanism,Top
218 PSHEZ0045AWZZ J AB Sheet D,LCD
219 PCUSZ0017AWZZ J AB Cushion,Cartridge
220 GFTAU3005AWSA J AS Bottom Cabinet [MD-MT15H-S]
220 GFTAU3013AWSA J AS Bottom,Cabinet [MD-MT161E]
220 GFTAU3014AWSA J AS Bottom Cabinet [MD-MT15H-RD]
220 GFTAU3015AWSA J AS Bottom Cabinet [MD-MT18H]
220 GFTAU3016AWSA J AS Bottom Cabinet [MD-MT15-S]
220 GFTAU3017AWSA J AS Bottom Cabinet [MD-MT15C-S]
220 GFTAU3018AWSA J Bottom Cabinet [MD-MT15W]
221 JKNBZ0625AWSA J AD Button,Hold
222 GCOVA1241AWSA J AC Cover,DC IN Jack
223 PSHET0014AWZZ J AE Sheet,Bottom Cabinet
To Next Page
