Sharp MX-2300G Service Manual

MX3500N SIMULATION 7 – 4
22 10 Used to check the system configuration (option, internal hardware). – Adjustment/Setup/Operation
data check
11 Used to check the use frequency (send/receive) of FAX. (Only when FAX is
installed)
FAX Adjustment/Setup/Operation
data check
12 Used to check the RSPF/DSPF misfeed positions and the number of misfeed at
each position. (When the number of misfeed is considerably great, it can be
judged as necessary for repair.)
RSPF/DSPF Adjustment/Setup/Operation
data check
13 Used to check the operating time of the process section (OPC drum, DV unit,
toner cartridge).
– Adjustment/Setup/Operation
data check
19 Used to check the values of the counters related to the scan mode and the
internet FAX mode.
Scanner Adjustment/Setup/Operation
data check
90 Used to output the various set data lists. – Adjustment/Setup/Operation
data check
23 2 Used to check the trouble history of paper jam and misfeed. (If the number of
misfeed and troubles is considerably great, it may be judged as necessary to
repair.)
– Adjustment/Setup/Operation
data check
80 Used to check the operations of the sensors and detectors in the paper feed and
transport section.
Paper feed, transport Operation test/Check
24 1 Used to clear the jam counter, and the trouble counter. (The counters are
cleared after completion of maintenance.)
– Data clear
2 Used to clear the number of use (the number of prints) of each paper feed
section.
– Data clear
3 Used to clear the number of use of the finisher, RSPF, DSPF, and the scan
(reading) unit.
– Data clear
4 Used to clear the maintenance counter, the printer counters of the transfer unit
and the fusing unit. (After completion of maintenance, clear the counters.)
– Data clear
5 Used to clear the developer counter. (After replacement of developer, clear the
counter.)
– Data clear
6 Used to clear the copy counter. – Data clear
7 Used to clear the OPC drum counter. (After replacement of the OPC drum, clear
the counter.)
– Data clear
9 Used clear the printer mode print counter and the self print mode print counter. – Data clear
10 Used to clear the FAX counter. (Only when FAX is installed) – Data clear
15 Used to clear the counters related to the image send. – Data clear
30 Used to initialize the administrator password. – Data clear
31 Used to initialize the service mode password. – Clear
25 1 Used to check the operations of the developing section. Process (Developing
section)
Operation test/Check
2 Used to make the initial setting of toner concentration when replacing developer. Process (Photoconductor/
Developing/Transfer/
Cleaning)
Setting
26 1 Used to set the paper exit tray (MX-TRX1). Paper exit Setting
2 Used to set the paper size of the large capacity tray (LCC). (When the paper
size is changed, this simulation must be executed to change the paper size in
software.)
Paper feed Setting
3 Used to set the specifications of the auditor. Auditor Setting
5 Used to set the count mode of the total counter and the maintenance counter. – Setting
6 Used to set the specifications (paper, fixed magnification ratio, etc.) of the
destination.
– Setting
10 Used to set the trial mode of the network scanner. – Setting
18 Used to set the toner save mode. – Setting
30 Used to set allow/inhibit of HL slow-up control (CE mark support control). – Setting
35 Used to set the trouble memory saving procedure. – Setting
38 Used to set Continue/Stop of print when the developer life is reached. Other Setting
41 Used to set YES/NO of AMS setting in the center binding mode. – Setting
49 Used to set the copy speed mode. – Setting
50 Used to set functions. – Setting
52 Used to set whether non-printed paper (insertion paper, cover paper) is counted
up or not.
– Setting
53 Used to set YES/NO of the auto color calibration. – Setting
54 Used to set the printer calibration YES/NO. Printer Setting
65 Used to set the finisher alarm mode. – Setting
67 Used to set the summer time (switching timing to the summer time and the
adjustment time (shift amount)) and the time zone (for switching to the summer
time and the difference between the local time and GMT (UTC) for
synchronization with the internet time server).
– Setting
69 Used to set whether the toner preparation message and the toner near end
message are displayed or not when the toner quantity reaches 25%.
Process Setting
27 1 Used to set whether the detection of communication error with RIC (U7-00) is
disabled or not.
Communication (RIC/
MODEM)
Operation test/Check
2 Used to set the FSS function (Sender registration number, HOST server TEL
number).
Communication (RIC/
MODEM)
Setting
Code
Function (Purpose) Section Purpose
Main Sub
