MX3500N SIMULATION 7 – 6
44 22 Used to check the toner patch image density level of each color in half tone
image forming section correction (process correction). (This simulation is used
to check that the correction is normally executed or not.)
Process Adjustment/Setup/Operation
data output/Check (Display/Print)
24 (This simulation is not used in the market.)
Used to display the process control result.
Process Adjustment/Setup/Operation
data output/Check (Display/Print)
25 Used to check the initial condition of process control (half tone correction). Process Adjustment/Setup/Operation
data output/Check (Display/Print)
26 Used to execute the half tone process control forcibly. Process Adjustment
27 Used to clear the half tone process control correction value. Process Data clear
28 Used to set the timing (ON/OFF) of process control execution. Process Setting
29 Enable/disable of the half tone correction during each job is switched. Process Setting
31 Used to perform the phase adjustment for OPC drum deflection. (Used to adjust
the phases of four OPC drums deflection.)
Process (OPC drum) Adjustment
43 Used to display each developing unit installing state AD value.
This simulation is added to check the sampling data of the detection judgment of
developing unit installation not only as the judgment result (trouble display) but
also as the current state value.
Process (Developing) Adjustment/Setup/Operation
data output/Check (Display/Print)
52 (This function is not used. Do not operate.)
Used to check the toner patch image density level of each color in 1 pixel half
tone correction. (The simulation is used to check whether the correction is
normally executed or not.)
Process Adjustment/Setup/Operation
data output/Check (Display/Print)
54 (This function is not used. Do not operate.)
Used to display the 1 pixel half tone correction result.
Process Adjustment/Setup/Operation
data output/Check (Display/Print)
56 (This function is not used. Do not operate.)
Used to perform the forcible execution of 1 pixel half tone correction.
Process Setting
57 (This function is not used. Do not operate.)
Used to clear the correction value of 1 pixel half tone correction.
Process Data clear
46 1 Used to set the default exposure (color copy) for every document mode. Scanner Adjustment
2 Used to adjust the exposure in BLACK copy. Scanner Adjustment
4 Used to adjust the exposure of the color scanner. Scanner Adjustment
5 Used to adjust the exposure of the black scanner. Scanner Adjustment
8 Used to make the scanner color balance RGB adjustment (for color push
scanner mode).
Scanner Adjustment
9 Used to adjust the exposure. RSPF/DSPF Adjustment
10 Used to the copy density adjustment (manual). (color mode) Engine Adjustment
16 Used to the copy density adjustment (manual) [Monochrome, all modes] PG
print.
Engine Adjustment
19 Used to set the BLACK auto exposure mode. Scanner Adjustment
21 Used to perform the copy color balance manual correction. [Color, All modes]:
PG print
Engine Adjustment
23 Used to set ENABLE/DISABLE of the half tone highest density correction. – Setting
24 Used to the copy color balance auto adjustment. Engine Adjustment
25 Used to execute the fine adjustment of single color mode color balance. Image process (ICU) Adjustment
26 Used to reset the single color mode color balance set value to the default. Image process (ICU) Adjustment
27 Used to set the engine gamma calculating formula coefficient. Image process (ICU) Adjustment
28 (Information on this simulation may be requested in some cases. However, this
function is basically not used in the market.)
Used to check the auto exposure/Auto document recognition/ Line number
recognition (Color mode). If the local memory size is less than 256MB, the
operation of this simulation may not operate normally.
Image process (ICU) Adjustment
33 Used to execute the color auto mode adjustment. Image process (ICU) Setting
36 Used to perform the fine adjustment of 2-color (Red, Black) copy. – Adjustment
37 Used to perform the BLACK image forming adjustment. – Adjustment
39 Used to execute the image send sharpness adjustment. (Only when FAX is
installed)
FAX Adjustment
40 Used to execute the FAX exposure adjustment. (Collective adjustment of all the
modes). (Only when FAX is installed)
ICU/FAX Adjustment
41 Used to execute the FAX exposure adjustment (Normal). (Only when FAX is
installed)
ICU/FAX Adjustment
42 Used to execute the FAX exposure adjustment (Fine text). (Only when FAX is
installed)
ICU/FAX Adjustment
43 Used to execute the FAX exposure adjustment (Super Fine). (Only when FAX is
installed)
ICU/FAX Adjustment
44 Used to execute the FAX exposure adjustment (Ultra Fine). (Only when FAX is
installed)
ICU/FAX Adjustment
45 Used to execute the FAX exposure level adjustment and the individual setting
(600DPI). (Only when FAX is installed)
FAX Adjustment
47 Used to set the JPEG compression rate in Copy/Scanner (PUSH SCAN). – Setting
48 1 Used to execute the magnification adjustment in the scan system. RSPF/DSPF/Scanner Adjustment
Code
Function (Purpose) Section Purpose
Main Sub
