MX3500N SIMULATION 7 – 8
55 1 Used to set the engine soft SW. PCU Setting
2 Used to set the scanner soft SW Scanner Setting
3 Used to set the controller soft SW. MFP Setting
56 1 Used to execute data transfer. MFP Data transfer
2 Used to backup the data (user authentication data, address book, etc.) of
EEPROM, SRAM, or HDD to a USB memory and to restore the data.
Memory, HDD Backup
60 1 Used to check read/write of the expansion DIMM installed to the MFPcnt PWB.
After completion of execution, the result of each slot is displayed on the panel.
MFPcnt PWB image DRAM read/write operation check, check MFP (memory)
operation.
Image process (MFP) Operation test/Check
2 Used to set the data of onboard SDRAM. – Setting
61 1 The polygon motor rotation and the BD signal detection are checked. LSU Operation test/Check
4 Used to execute self-print of the LSU position adjustment. LSU Adjustment
62 1 Used to execute the hard disk format (except operation manual area).
* Be sure to format the HDD in FAT32.
MFP (HDD) Data clear
2 Used to execute the partial check of the hard disk read/write.
* Be sure to format the HDD in FAT32.
MFP (HDD) Operation test/Check
3 Used to execute read/write check (all areas) of the hard disk.
* Be sure to format the HDD in FAT32.
MFP (HDD) Operation test/Check
6 Used to execute the HDD self-diagnostics.
* Be sure to format the HDD in FAT32.
MFP (HDD) Operation test/Check
7 Used to print the self-diagnostics error log.
* Be sure to format the HDD in FAT32.
MFP Operation test/Check
8 Used to format the hard disk excluding the system area and operation manual
area.
* Be sure to format the HDD in FAT32.
MFP (HDD) Data clear
10 Used to delete the job completion list. (The job log data are also deleted.)
* Be sure to format the HDD in FAT32.
MFP (HDD) Data clear
11 Used to delete the document filing data.
* Be sure to format the HDD in FAT32.
MFP (HDD) Data clear
12 Used to set Enable/Disable of auto format in HDD trouble.
* Be sure to format the HDD in FAT32.
MFP (HDD) Data clear
13 Used to format the hard disk (operation manual area only).
* Be sure to format the HDD in FAT32.
MFP (HDD) Data clear
63 1 Used to check the following values related to shading for RGB and OC/RSPF/
DSPF. (3 x 2 = 6 kinds)
Scanner (Exposure) Adjustment/Setup/Operation
data output/Check (Display/Print)
2 Used to execute shading forcibly (MX-3500N/4500N). Scanner Adjustment
2 Used to execute shading forcibly (MX-3501N/4501N). Scanner Adjustment
3 Used to execute the gamma correction and density conversion for RGB image
data inputted from the CCD. Gamma correction 1 of the SCAN ASIC and the set
value of color correction are set by calculating from the image data.
Scanner (scan) Adjustment
5 Used to reset the gamma correction and color correction parameters of the
SCAN ASIC.
Scanner Adjustment
6 Used to scan the engine color balance auto adjustment pattern and to display
the sampling result.
Image process (ICU) Adjustment/Setup/Operation
data output/Check (Display/Print)
7 Used to display and register the engine auto density adjustment scanner target
value (for servicing).
Image process (ICU) Setting
8 Used to execute the standard value reset of the engine auto adjustment scanner
target value (for servicing).
Image process (ICU) Setting
11 Used to set the factory target color balance in the auto color balance adjustment
(SIM46-24).
Scanner (Scanning) Setting
64 1 Used to execute self-print (Color mode). Printer Operation test/Check
2 Used to print the density adjustment pattern. Printer Adjustment/Setup/Operation
data output/Check (Display/Print)
3 Used to execute self-print. (BW mode) Printer Operation test/Check
4 Used to execute self-print. Printer Operation test/Check
5 Used to execute self print (PCL). Printer Operation test/Check
6 Used to execute the printer self print (PS). Printer Operation test/Check
65 1 Used to adjust the touch panel (LCD display section) detection position. Operation panel Adjustment
2 Used to check the touch panel (LCD display section) detection position
adjustment result.
Operation panel Adjustment/Setup/Operation
data output/Check (Display/Print)
67 24 Use to execute the printer setting of auto color calibration. Printer Adjustment
25 Used to set the manual correction of the printer engine color balance. Printer Adjustment
26 Used to set the reference scanner target value of the printer engine auto density
adjustment of Simulation 67-24.
Compaired to DEF1, DEF2 and DEF3 are decreased-red color balance target
value.
Printer Adjustment
27 Used to display and register the scanner target value (for servicing) of the
printer engine auto density adjustment.
Printer Adjustment
28 The scanner target value (for servicing) of the printer engine auto density
adjustment is reset to the standard value.
Scanner Adjustment
30 Used to set YES/NO of delivery of the main unit calibration data and the process
control correction data to the client PC by the GDI printer.
Printer Setting
Code
Function (Purpose) Section Purpose
Main Sub
