Sharp MX-2300G Service Manual

MX3500N SIMULATION 7 – 10
2
2-1
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the auto-
matic document feeder unit and the control
circuit.
Section
RSPF/DSPF
Item
Operation
Operation/Procedure
1) Select the operation mode with the buttons on the touch panel.
2) Select the aging mode with [1SIDE] and [2SIDE] buttons on
the touch panel (MX-3500N/4500N only).
3) Select the magnification ratio with [ZOOM] button on the touch
panel.
4) Press [EXECUTE] button.
Aging is performed in the mode corresponding to the operation
mode.
* When [EXECUTE] button is pressed during aging, the oper-
ation is terminated and [EXECUTE] button returns to the
original state.
2-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the sen-
sors and detectors in the automatic docu-
ment feeder unit and the related circuits.
Section
RSPF/DSPF
Item
Operation
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The active sensors and detectors are highlighted.
(MX-3500N/4500N)
NOTE: SWD_LEN and SWD_AD are not ON/OFF display.
(MX-3501N/4501N)
NOTE: SWD_LEN and SWD_AD are not ON/OFF display.
2-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the loads
in the automatic document feeder unit and
the control circuits.
Section
RSPF/DSPF
Item
Operation
Operation/Procedure
1) Select the item to be checked with the buttons on the touch
panel.
2) Press [EXECUTE] button.
The selected load operation is performed.
When [EXECUTE] button is pressed, the operation is termi-
nated.
Button
display
Content
Selectable
magnification ratio
Default
value
50 Scan magnification ratio:
50%
COLOR: 50%, 100%,
200%
BLACK (High speed):
100%, 200%
BLACK (Low speed):
50%, 100%, 200%
100%
100 Scan magnification ratio:
100%
200 Scan magnification ratio:
200%
SSET RSPF installation detection
SOCD RSPF open/close detection
SCOV RSPF cover SW
SPED RSPF document empty detection
SPPD1 RSPF paper entry detection 1 and random detection
(common)
SPPD2 RSPF paper entry detection 2 PS front
SPPD3 RSPF before-scan detection
SPPD4 RSPF reverse gate front detection
SPPD5 RSPF reverse rear detection
SPLS1 RSPF document length detection short
CLOSE
BLACK(SLOW)
0
SIMULATION NO.02-01
RSPF AGING
TEST
EXECUTE
150 200
ZOOM
100
%
BLACK(FAST) COLOR
2-SIDE
1-SIDE
25
50
100
300
400
SPLS2 RSPF document length detection long
STMPU RSPF stamp unit installation detection
SWD_LEN RSPF guide plate position
SWD_AD RSPF document detection volume output
SSET DSPF installation detection
SOCD DSPF open/close detection
SCOV DSPF cover SW
SLCOV DSPF lower door open/close detection
SPED1 DSPF document empty detection
SPED2 DSPF document detection
SPPD1 DSPF document pass detection 1
SPPD2 DSPF document pass detection 2
SPPD3 DSPF document pass detection 3
SPPD4 DSPF document pass detection 4
SPPD5 DSPF document pass detection 5
SPOD DSPF paper exit detection
SPRDMD DSPF random feed paper size detection
SPLS1 DSPF document length detection short
SPLS2 DSPF document length detection long
STLD DSPF document tray lower limit detection
STUD DSPF document tray upper limit detection
STMPU DSPF stamp unit installation detection
SWD_LEN DSPF guide plate position
SWD_AD DSPF document detection volume output
0
RSPF SENSOR CHECK SWD_LEN: **** SWD_AD: ***
1/1
CLOSE
SIMULATION NO.02-02
TEST
1/1
SSET
SOCD
SCOV
SPED
SPPD1 SPPD2
SPPD3
SPPD4
SPPD5
SPLS1 SPLS2
STMPU
0
DSPF SENSOR CHECK SWD_LEN: **** SWD_AD: ***
1/1
CLOSE
SIMULATION NO.02-02
TEST
1/2
SSET SOCD SCOV SLCOV
SPRDMD SPLS1 SPLS2 STLD
SPED1 SPED2 SPPD1 SPPD2
SPPD3 SPPD4 SPPD5 SPOD
