Sharp MX-2300G Service Manual

MX3500N SIMULATION 7 – 11
(MX-3500N/4500N)
*1: Since the stamp solenoid is an option unit, it can be operated
only when it is installed.
* For the same loads displayed separately depending on normal
rotation and rotation, if they are selected together, normal rota-
tion is performed.
In addition, if the load is rotating, reverse rotation is not accepted
until the operation is stopped.
(MX-3501N/4501N)
*1: Since the stamp solenoid is an option unit, it can be operated
only when it is installed.
3
3-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operation of sensor and
detector in the finisher and the related cir-
cuit.
Section
Finisher
Item
Operation
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The active sensors and detectors are highlighted.
<Saddle finisher (MX-FNX2)>
<Saddle finisher punch unit (AR-PN1A/B/C/D)>
<Inner finisher (MX-FNX1)>
SPFM RSPF transport motor
SPRM_F RSPF paper feed reverse motor normal rotation
SPRM_R RSPF paper feed reverse motor reverse rotation
SPFC RSPF paper feed clutch
SRRC RSPF resist roller clutch
SGS RSPF document exit gate solenoid
STMPS Finish stamp solenoid (*1)
SPUM DSPF paper feed motor
SPFM DSPF transport motor
SPOM DSPF paper exit motor
SLUM DSPF lift motor
SPFFAN DSPF fan motor
SPFC DSPF paper feed clutch
SRRC DSPF resist roller clutch
SRRBC DSPF resist roller break clutch
STRRC DSPF No. 1 resist roller clutch
STRRBC DSPF No. 1 resist roller break clutch
STRC DSPF transport clutch
STMPS Stamp solenoid (*1)
㩷
㩷
㩷
㩷
㩷
㩷
SIMULATION  NO.02  03
TEST
RSPF OUTPUT CHECK
 SPFM
SPRM_F
SPRM_R
SPFC
SRRC
SGS
1/1
EXECUTE
0
 STMPS
CLOSE
㩷
㩷
SIMULATION  NO.02  03
TEST
DSPF OUTPUT CHECK
SPUM SPFM
SPOM SLUM
SPFFAN SPFC
1/2
EXECUTE
0
SRRC
CLOSE
SRRBC
FJPID Interface transport unit entry port detection
FJPOD Interface transport unit exit port detection
FJPDD Interface transport unit cover detection
FED Entry port paper detection
FPDHPD Paddle HP detection
FARHPD Bundle roller HP detection
FFJHPD Alignment plate HP detection front
FRJHPD Alignment plate HP detection rear
FAD Alignment tray detection
FOBHPD Discharge belt HP detection
FBED Tray paper detection
FSLD Paper surface detection
FFPD Binding position detection
FFHPD Binding HP detection
FFRHPD Binding roller HP detection
FFED Binding paper detection
FFE Binding lock detection
FULD Lift upper limit detection
FLLD Lift lower limit detection
FLE Lift lock detection
FSHPD Staple drive HP detection
FSTHPD Staple shift HP detection
FSD Staple empty detection
FSUC Staple connection detection
FSPD Self prime detection
FMLD Tray intermediate detection
FFDD Front door detection
FCD Upper cover detection
FFDSW Front door SW detection
FJSW Joint SW detection
FSSSW Staple safety SW detection
FFANLK Fan motor lock detection
FPE Punch motor lock detection
FPUC Punch unit connection detection
FPHPD Punch HP detection
FPDD Punch dust detection
FPSHPD Punch horizontal resist HP detection
FPTD Punch timing detection
FPSD1 Punch horizontal resist detection 1
FPSD2 Punch horizontal resist detection 2
FPSD3 Punch horizontal resist detection 3
FPSD4 Punch horizontal resist detection 4
FED Entry port paper detection
FBED Tray paper detection
FULD Tray upper limit detection
FMLLD Tray intermediate lower limit detection
FLLD Tray lower limit detection
FSLD1 Paper surface detection 1
FSLD2 Paper surface detection 2
FRLD Roller up/down detection
FBRD Belt separation detection
FFJHPD Alignment plate HP detection front
FRJHPD Alignment plate HP detection rear
FJPD Alignment guide position detection
FSTPD Staple tray paper detection
FSHPD Staple drive HP detection
FSTHPD Staple shift HP detection
FSD Staple empty detection
FSTD Staple lead edge position detection
FDSW Door open detection
FFANLK Fan motor lock detection
