MX3500N SIMULATION 7 – 23
22-3
Purpose
Adjustment/Setup/Operation data check
Function (Purpose)
Used to check misfeed positions and the
misfeed count of each position.
Section
—
Item
Trouble
Operation/Procedure
The history of paper jams and misfeed is displayed.
The above histories are displayed from the newest one to the old-
est in this sequence. The max. 50 items are saved. (The oldest one
is sequentially erased.)
* List of JAM codes: Refer to "2. Paper JAM code" in the "[12]
OTHERS."
22-4
Purpose
Adjustment/Setup/Operation data check
Function (Purpose)
Used to check the trouble (self diag) his-
tory.
Section
—
Item
Trouble
Operation/Procedure
The trouble history is displayed.
The trouble history is displayed sequentially from the latest one.
The max. 30 items can be stored. (The oldest one is deleted
sequentially.)
Press [COLOR] or [BLACK] button to print.
* Trouble code list: Refer to "2. Trouble code list" in the "[8] SELF
DIAG AND TROUBLE CODE".
22-5
Purpose
Others
Function (Purpose)
Used to check the ROM version of each
unit (section).
Section
—
Item
Software
Operation/Procedure
The ROM version can be checked with [↑] [↓] buttons.
When there is any problem in the software, use this simulation to
check the ROM version of each section and revise the version if
necessary.
Press [COLOR] or [BLACK] button to print.
22-6
Purpose
Adjustment/Setup/Operation data check
Function (Purpose)
Used to output the list of the setting and
adjustment data (simulations, FAX soft
switch, counters).
Section
—
Item
Data (Setting, adjustment data)
Operation/Procedure
* When installing or servicing, this simulation is executed to print
the adjustment data and set data for use in the next servicing.
(Memory trouble, PWB replacement, etc.)
1) Select the print mode with 10-key.
2) Press [EXECUTE] button.
The list print selected in step 1) is started.
* When [C] key, [CA] key, [SYSTEM SETTINGS] key, or [EXE-
CUTE] button is pressed during printing, the operation is ter-
minated.
MACHINE JAM
SIMULATION NO.22-02
TEST
JAM/TROUBLE COUNTER DISPLAY
CLOSE
RSPF/DSPF JAM
TROUBLE
: 00000000
: 00000000
: 00000000
1/1
0
0
CLOSE
JAM HISTORY DATA DISPLAY
1/1
SIMULATION NO.22-03
TEST
1/1
PPD2_N1 CPFD2_S2 MFT TRAY3
PPD2_N1 CPFD2_S2 APPD3_S DPFD2_S4
LCC PPD2_PRI CPID2_S2 CPID2_S2
CPFD1_N1 PPD2_PRI TRAY3 APPD3_S
TRAY2 MFT
0
CLOSE
TROUBLE CODE DATA DISPLAY
SIMULATION NO.22-04
TEST
1/2
E7-23 F9-20 F2-39 L4-31
F1-50 L4-02 F2-39 F1-50
F1-50 L4-02 F1-61 F1-50
F1-50 F2-39 H5-01 E7-23
U5-12 F2-39 L1-00 E7-23
S/N Serial No.
ICU(MAIN) ICU (Main section)
ICU(BOOT) ICU (Boot section)
LANGUAGE Language support data version
GRAPHIC Graphic data for LCD
IMG DATA ROM ImageASIC FlashROM data
COLOR PROFILE Color profile
PCU PCU
SCU SCU
SPF SPF
FAX1(MAIN) FAX1 line (Main section)
FAX2(MAIN) FAX2 line (Main section)
DESK Desk unit
LCC Side LCC
FINISHER Finisher
SADDLE Saddle unit
PUNCH Punch unit
NIC NIC
EFI EFI
POWER-CON Power controller
E-MANUAL Operation manual (HDD storage)
SIMULATION NO.22-05
S/N : **********
TEST
CLOSE
0
ICU(MAIN) : 00.00.00
ICU(BOOT) : 00.00.00
LANGUAGE : 00.00.00
GRAPHIC : 00.00.00
IMG DATA ROM : 00.00.00
COLOR PROFILE : 00.00.00
PCU : 00.00.00
SCU : 00.00.00
SPF : 00.00.00
FAX1(MAIN) : NONE
1/2
To Next Page
