MX3500N SIMULATION 7 – 24
22-8
Purpose
Adjustment/Setup/Operation data check
Function (Purpose)
Used to check the number of use of the fin-
isher, the RSPF, the DSPF, and the scan
(reading) unit.
Section
—
Item
Counter
Operation/Procedure
The values of the finisher counter, the RSPF counter, the DSPF
counter, and the scanner (read) related counters are displayed.
Press [COLOR] or [BLACK] button to print.
22-9
Purpose
Adjustment/Setup/Operation data check
Function (Purpose)
Used to check the number of use (print
quantity) of each paper feed section.
Section
Paper feed, ADU, LCC
Item
Counter
Operation/Procedure
The values of the paper feed related counters are displayed.
Press [COLOR] or [BLACK] button to print.
22-10
Purpose
Adjustment/Setup/Operation data check
Function (Purpose)
Used to check the system configuration
(option, internal hardware).
Section
—
Item
Specifications (Option)
Operation/Procedure
1) The system configuration is displayed. (The model names of
the installed devices and options are displayed.)
2) Change the display with [↑] [↓] buttons.
Press [COLOR] or [BLACK] button to print.
Item
Display item &
detail display
Description
Set
range
Default
value
A DATA PATTERN Data pattern selection
1: List print
2: List print (Sim50-24)
1 to 2 1
RSPF/DSPF Document feed quantity
SCAN Number of scan
STAPLER Staple counter
PUNCHER Puncher counter
STAMP Stamp counter
SADDLE STAPLER Saddle staple counter
OC_OPEN OC open/close counter
RSPF/DSPF_OPEN RSPF/DSPF open/close counter
OC LAMP TIME Total lighting time of the lamp in OC section
DSPF LAMP TIME Total lighting time of the lamp in DSPF section
TRAY1 Tray 1 paper feed counter
TRAY2 Tray 2 paper feed counter
TRAY3 Tray 3 paper feed counter
TRAY4 Tray 4 paper feed counter
MFT TOTAL Manual paper feed counter (Total)
MFT HEAVY Manual paper feed counter (Heavy paper)
MFT OHP Manual paper feed counter (OHP)
0
A:
A: 1
; DATA PATTERN
SIMULATION NO.22-06
DATA PRINT MODE
1
[1~2]
OK
TEST
EXECUTE
CLOSE
RSPF/DSPF : 00000000
SCAN : 00000000
STAPLER : 00000000
PUNCHER : 00000000
STAMP : 00000000
SIMULATION NO.22-08
TEST
ORG./STAPLE COUNTER DISPLAY
CLOSE
SADDLE STAPLER : 00000000
OC_OPEN : 00000000
RSPF/DSPF_OPEN : 00000000
OC LAMP TIME : 00000:00
DSPF LAMP TIME : 00000:00
0
1/1
MFT ENV Manual paper feed counter (Envelope)
LCC Side LCC paper feed counter (A4 or A3 LCC)
ADU ADU paper feed counter
Item display Display content Content
MACHINE MX-3500FN Machine
MX-4500FN
MX-3501FN
MX-4501FN
MX-3500N
MX-4500N
MX-3501N
MX-4501N
RSPF/DSPF MX-RPX1/
STANDARD
Document feed unit
STAMP AR-SU1 Finish stamp
DESK MX-DEX3 Desk unit
MX-DEX4
LCC MX-LCX1 Large capacity cassette (Side
LCC)
PUNCHER MX-PNX1A Punch unit
MX-PNX1B
MX-PNX1C
MX-PNX1D
AR-PN1A
AR-PN1B
AR-PN1C
AR-PN1D
FINISHER MX-FNX2 Finisher
MX-FNX1
FAX1 MX-FXX1 FAX kit
FAX2 MX-FLX1 FAX 2 line kit
FAX MEMORY AR-MM9 FAX expansion memory
MX-MMX1
HAND SET MX-HNX1 Handset
NETWORK
SCANNER
MX-NSX1 Network scanner expansion kit
PRINTER MX-PBX1 Printer expansion kit
PS MX-PKX1 PS expansion kit
SECURITY MX-FRX2 Security kit
AIM MX-AMX1 Application expansion kit
SDRAM(SYS) *****MB SDRAM capacity
SDRAM(ICU) *****MB SDRAM capacity
HDD *****MB Hard disk capacity
NIC STANDARD NIC
BARCODE AR-PF1 Barcode font
INTERNET-FAX MX-FWX1 Internet Fax expansion kit
TRAY1 : 00000000
TRAY2 : 00000000
TRAY3 : 00000000
TRAY4 : 00000000
MFT TOTAL : 00000000
SIMULATION NO.22-09
TEST
PAPER FEED COUNTER DISPLAY
CLOSE
MFT HEAVY : 00000000
MFT OHP : 00000000
MFT ENV : 00000000
LCC : 00000000
ADU : 00000000
1/1
0
