MX3500N SIMULATION 7 – 25
22-11
Purpose
Adjustment/Setup/Operation data check
Function (Purpose)
Used to check the use frequency (send/
receive) of FAX. (Only when FAX is
installed)
Section
FAX
Item
Counter
Operation/Procedure
The values of the FAX send counter and the FAX receive counter
are displayed.
Press [COLOR] or [BLACK] button to print.
22-12
Purpose
Adjustment/Setup/Operation data check
Function (Purpose)
Used to check the RSPF/DSPF misfeed
positions and the number of misfeed at
each position. (When the number of mis-
feed is considerably great, it can be judged
as necessary for repair.)
Section
RSPF/DSPF
Item
Function
Operation/Procedure
The history of paper jam and misfeed is displayed.
The misfeed history is displayed sequentially from the latest one.
The max. 50 items are recorded. (The oldest one is sequentially
deleted.) This data can be used to identify the trouble position.
Press [COLOR] or [BLACK] button to print.
List of JAM codes: Refer to "2. Paper JAM code" in the "[12] OTH-
ERS".
22-13
Purpose
Adjustment/Setup/Operation data check
Function (Purpose)
Used to check the operating time of the
process section (OPC drum, DV unit, toner
cartridge).
Section
—
Item
Counter
Operation/Procedure
The rotating time and the print quantity of the process section are
displayed.
Change the display with [↑] [↓] buttons.
Press [COLOR] or [BLACK] button to print.
FAX OUTPUT FAX print quantity counter (for line 1)
FAX OUTPUT_L2 FAX print quantity counter (for line 2)
FAX SEND FAX send counter
FAX RECEIVED FAX receive counter
SEND IMAGES FAX send quantity counter (for line 1)
SEND IMAGES_L2 FAX send quantity counter (for line 2)
SEND TIME FAX send time
RECEIVED TIME FAX receive time
ACR SEND Number of carrier prefix adding communications
SIMULATION NO.22-10
MACHINE SYSTEM
TEST
CLOSE
0
MACHINE : MX-3500N
RSPF/DSPF
: MX-RPX1/STANDARD
STAMP
: AR-SU1
DESK
: MX-DEX3
LCC
: MX-LCX1
PUNCHER
: MX-PNX1A
FINISHER
: MX-FNX1
FAX䋱
: MX-FXX1
1/3
FAX2 : MX-FLX1
FAX MEMORY
: AR-MM9
FAX O UTPUT
SI MU LATI O N

NO.22

11
TEST
FAX COUNTER DISPLAY
CLOSE
00000000
㧦 SEND IMAGES_L2
00000000
㧦
FAX O UTPUT_L2
 00000000
㧦
SEND TIME
00000000:00:00
㧦
FAX SEND
 00000000
㧦
RECEIVED TIME
00000000:00:00
㧦
FAX RECEIVED
 00000000
㧦
CR SEND
㧦
SEND IMAGES  00000000
㧦
1/1
0
00000000
DRUM CTRG K Drum cartridge print counter (K)
DRUM CTRG C Drum cartridge print counter (C)
DRUM CTRG M Drum cartridge print counter (M)
DRUM CTRG Y Drum cartridge print counter (Y)
DRUM RANGE K Drum cartridge accumulated traveling distance
(CM)(K)
DRUM RANGE C Drum cartridge accumulated traveling distance
(CM)(C)
DRUM RANGE M Drum cartridge accumulated traveling distance
(CM)(M)
DRUM RANGE Y Drum cartridge accumulated traveling distance
(CM)(Y)
DEVE CTRG K Developer cartridge print counter (K)
DEVE CTRG C Developer cartridge print counter (C)
DEVE CTRG M Developer cartridge print counter (M)
DEVE CTRG Y Developer cartridge print counter (Y)
DEVE RANGE K Developer cartridge accumulated traveling distance
(CM)(K)
DEVE RANGE C Developer cartridge accumulated traveling distance
(CM)(C)
DEVE RANGE M Developer cartridge accumulated traveling distance
(CM)(M)
DEVE RANGE Y Developer cartridge accumulated traveling distance
(CM)(Y)
TONER MOTOR K Toner motor print counter (K)
TONER MOTOR C Toner motor print counter (C)
TONER MOTOR M Toner motor print counter (M)
TONER MOTOR Y Toner motor print counter (Y)
TONER TURN K Toner motor accumulated rotation time (SEC)(K)
TONER TURN C Toner motor accumulated rotation time (SEC)(C)
TONER TURN M Toner motor accumulated rotation time (SEC)(M)
TONER TURN Y Toner motor accumulated rotation time (SEC)(Y)
CLOSE
SIMULATION

NO.22
㧙
12
52(,#/*+5614;#&+52.#;
TEST
CLOSE
0





















DRUM CTRG K
SIMULATION

NO.22

13
TEST
PROCESS CARTRIDGE DISPLAY
CLOSE
00000000
:
DRUM R AN G E K
00000000
:
DRUM CTRG C
 00000000
:
DRUM R AN G E C
00000000
:
DRUM CTRG M
 00000000
:
DRUM R AN G E M
00000000
:
DRUM CTRG Y
 00000000
:
DRUM R AN G E Y
00000000
:

1/2
