Sharp MX-2300G Service Manual

MX3500N SIMULATION 7 – 40
27-2
Purpose
Setting
Function (Purpose)
Used to set the FSS function (Sender regis-
tration number, HOST server TEL number).
Section
Communication (RIC/MODEM)
Item
Data (User data)
Operation/Procedure
1) When the machine enters Simulation 27-02, the screen is dis-
played.
2) Select a desired button.
The button is highlighted and the value is displayed.
3) Enter the set value with 10-key. The entered value is displayed
at "NEW."
* Press [C] key to clear the entered value.
4) When [SET] button is pressed, the entered value is set.
When the entered value is set, it is displayed in "PRESENT:"
<Item and content descriptions>
27-4
Purpose
Setting
Function (Purpose)
Used to set the FSS functions (initializing,
call, toner order auto send).
Section
Communication (RIC/MODEM)
Item
Data (User data)
Operation/Procedure
1) When the machine enters the simulation, the following screen
is displayed.
2) Select an item to be set with [↑] and [↓] buttons.
The highlighted section of the set value is changed and the
value is displayed in the setting area.
* When there is an item over [↑], the display becomes active
and shifts to another item.
When there is no item over [↑], the display grays out and the
operation is disabled.
When there is an item under [↓], the display becomes active
and shifts to another item.
When there is no item under [↓], the display grays out and
the operation is disabled.
3) Enter the set value with 10-key.
* Press [C] key to clear the entered value.
4) When [OK] button is pressed, it is highlighted and the current
set value is saved to EEPROM and RAM.
After completion of setting, [OK] button returns to the normal
display.
* When [OK] button, [COLOR], or [BLACK] key is pressed, the
current set value is saved to EEPROM and RAM.
<Setting range and default value of each value>
Display Description Number of digits
USER FAX_NO. Sender registration number Max. 16 digits
SERVA TEL_NO. HOST server TEL number Max. 16 digits
 USER FAX_NO.  SERVA  TEL_NO
SIMULATION  NO.27-02
TEST
FSS FUNCTION SETUP㧔INPUT㧕
1/1
00000000000000000000000000000001
㧦
㧦
㧦
0
PRESENT
NEW
SET
CLOSE
Item Display Content
Setting
range
Default value Remark
A FSS MODE NEB1 FSS mode setting Only send in NE-B mode 0 1
NEB2 Send/Receive in NE-B mode 1
B RETRY Retry number setting 0 to 15 2 * 0: No retry
C TIMER (MINUTE) Retry timer setting (minute) 1 to 15 3
D TONER ORDER
TIMING (K)
100% – 75% Toner order auto send
timing setting (K)
100% to 75% 5 3 (49% to 25%)
74% – 50% 74% to 50% 4
49% – 25% 49% to 25% 3
LOWER 25 25% or less 2
NEAREND Near end 1
EMPTY Empty 0
E TONER ORDER
TIMING (C)
100% – 75% Toner order auto send
timing setting (C)
100% to 75% 5 3 (49% to 25%)
74% – 50% 74% to 50% 4
49% – 25% 49% to 25% 3
LOWER 25 25% or less 2
NEAREND Near end 1
EMPTY Empty 0
F TONER ORDER
TIMING(M)
100% – 75% Toner order auto send
timing setting (M)
100 to 75% 5 3 (49% to 25%)
74% – 50% 74% to 50% 4
49% – 25% 49% to 25% 3
LOWER 25 25% or less 2
NEAREND Near end 1
EMPTY Empty 0
G TONER ORDER
TIMING(Y)
100% – 75% Toner order auto send
timing setting (Y)
100% to 75% 5 3 (49% to 25%)
74% – 50% 74% to 50% 4
49% – 25% 49% to 25% 3
LOWER 25 25% or less 2
NEAREND Near end 1
EMPTY Empty 0
