MX3500N SIMULATION 7 – 144
67-33
Purpose
Adjustment
Function (Purpose)
Used to execute the gamma correction
between printer screens. (for GDI)
Section
Printer
Item
Adjustment
Operation/Procedure
1) Use [K][C][M][Y] buttons to select a color. (The selected color
button is highlighted.)
Use [SCREEN] button to select a screen. (In this example,
SCREEN2 is selected.)
Select the set item with [↑] and [↓] buttons.
The highlighted set value is switched and the value is dis-
played in the setting area.
* If there is any item over [↑], an active display is made and
item is shifted.
If there is no item over [↑], the display grays out and the
operation is invalid.
If there is any item under [↓], an active display is made and
item is shifted.
If there is no item over [↓], the display grays out and the
operation is invalid.
2) Enter the set value with 10-key.
* Press [C] key to clear the entered values.
* Use [ ] [ ] buttons to change the set values collectively.
When the set value is not the upper limit (lower limit) value,
the value is increased (decreased) by 1. If the set value is
the upper limit (lower limit) value, it is not changed.
3) When [OK] button is pressed, the current set data are saved to
EEPROM and RAM.
* Also when [↑], [↓], [ ], [ ] button, or [COLOR], [BLACK]
key is pressed, the value is saved to EEPROM and RAM.
<Set range and default value of each setup>
<Selectable items on the screen>
(*): When SCREEN3 is displayed, [K] data only. When [C] [M] [Y]
button is pressed, the gray-out keys are disabled.
Item Display Description Set range
Default value
SCREEN1•3SCREEN2
KCMY
A POINT1 Point 1 0 to 255 128 128 128 128 128
B POINT2 Point 2 0 to 255 128 128 128 128 127
C POINT3 Point 3 0 to 255 128 127 127 128 127
D POINT4 Point 4 0 to 255 128 127 128 128 127
E POINT5 Point 5 0 to 255 128 127 127 126 126
F POINT6 Point 6 0 to 255 128 127 126 127 126
G POINT7 Point 7 0 to 255 128 123 124 124 123
H POINT8 Point 8 0 to 255 128 119 122 122 123
I POINT9 Point 9 0 to 255 128 111 116 117 121
J POINT10 Point 10 0 to 255 128 112 113 112 117
K POINT11 Point 11 0 to 255 128 106 108 115 116
L POINT12 Point 12 0 to 255 128 110 113 110 115
M POINT13 Point 13 0 to 255 128 120 112 117 118
N POINT14 Point 14 0 to 255 128 110 119 120 118
O POINT15 Point 15 0 to 255 128 110 119 121 116
Display Content
SCREEN1 1bit Photo
SCREEN2 1bit Graphic
SCREEN3 1bit Mono (*)
0
A:
A㧦128
B㧦128
C㧦128
; POINT1
; POINT2
; POINT3
SIMULATION NO.67-33
PRINTER SCREEN GAMMA ADJUSTMENT(SCREEN 1)
128
㨇 0 㨪 255㨉
OK
TEST
K
C
M
Y
CLOSE
SCREEN
D㧦128 ; POINT4
