Sharp MX-2300G Service Manual

MX3500N CONSUMABLE PARTS 3 – 3
B. Europe/UK/Australia/New Zealand/Taiwan
No. Item Content Life Model name Remarks
1 Upper heat roller kit Upper heat roller x 1 300K MX-450UH
Fuser gear x 1
Upper separation pawl x 4
Upper separation pawl SP-N x 4
Upper thermistor sub x 1
Upper thermistor side x 1
Upper thermistor CJ x 1
Upper heat roller bearing x 2
2 Lower heat roller kit Lower heat roller x 1 300K MX-450LH
Lower heat roller bearing x 2
Lower separation pawl/spring x 4
Lower thermistor x 1
3 Primary transfer belt kit Intermediate transfer belt x 1 150K MX-450B1
Primary transfer blade x 1
Primary transfer conductive collar x 4
PS paper dust removal cleaner x 1
Bearing x 4
4 Primary transfer roller kit Primary transfer roller x 4 300K MX-450X1
Belt drive gear x 1
5 Secondary transfer belt kit Secondary transfer belt x 1 300K MX-270B2
6 Secondary transfer roller kit Secondary transfer roller x 1 300K MX-450X2
Secondary transfer idle gear x 1
7 Filter kit Ozone filter x 1 150K MX-450FL For Europe/Oceania
Paper exit filter x 2
Ozone filter x 1 150K MX-270FLN For Taiwan
8 Web cleaning kit Web unit x 1 150K MX-450WC
Sub roller x 1
Sub roller bearing x 2
9 Waste toner box kit Waste toner box unit (with LSU cleaner x 3) x 1 40K MX-270HB Each color 5% coverage,
color ratios 43%
10 DV seal kit DV seal x 3 Black: 150K,
Color: 100K
MX-270DS
DV side seal F/R x 3
Toner filter x 3
11 Main charger kit Main charger unit x 1 Black: 150K,
Color: 100K
MX-270MK
Drum cleaning blade x 1
12 Staple cartridge Staple cartridge x 3 5000 times x 3 AR-SC2 For saddle finisher
(MX-FNX2)
13 Staple cartridge Staple cartridge x 3 5000 times x 3 MX-SCX1 For inner finisher
(MX-FNX1)
14 Primary transfer belt unit Primary transfer belt unit (For service rotation) x 1 — MX-450U1
15 Secondary transfer belt unit Secondary transfer belt unit (For service rotation) x 1 — MX-450U2
16 Fusing unit Fusing unit (For service rotation) (Heater lamp 230V) x 1 — MX-450FU
Fusing unit (For service rotation) (Heater lamp 100V) x 1 — MX-450FU2
5
7
7
1
: Jan. 15 2006, : Jul. 15 2006, : Feb. 15 2007
