MX3500N ADJUSTMENTS 6 – 32
(The following items affect the copy color balance/density
adjustment, and must be checked and adjusted before execu-
tion of the image quality adjustments.)
1) The following adjustment items must be adjusted properly.
2) The set values of the following simulations must be set to the
default values.
3) The following items (correction functions) of SIM 44-1 must be
set to ENABLE (default).
(The following items affect the copy color balance/density
adjustment, but it is not required to adjust them frequently.
When, however, a trouble occurs, check and adjust them.)
1) The following items must be adjusted properly.
(Relationship between the servicing job contents and the copy
color balance/density adjustment)
Note that the preliminary jobs before execution of the copy color
balance/density adjustment depend on the machine status and the
servicing conditions.
Follow the flowchart of the copy color balance/density adjustment
procedures depending on the actual conditions.
There are following four, major cases.
1) When installing the machine.
2) When the periodic maintenance is performed.
3) When a repair, an inspection, or a maintenance is performed.
(When a consumable part is replaced.)
4) When a repair, an inspection, or a maintenance is performed.
(Without replacement of a consumable part)
Job
No
Adjustment item
Simulation
to be used
ADJ
5
Image density
sensor, image
registration
sensor
adjustment
ADJ
5A
Color image sensor calibration 44-13
ADJ
5B
Color image density sensor,
black image density sensor,
image registration sensor
adjustment
44-2
ADJ
6
Image skew adjustment (LSU (writing) unit) 64-1/61-4
ADJ
7
OPC drum
phase
adjustment
ADJ
7A
OPC drum phase adjustment
(Auto adjustment)
50-22
ADJ
7B
OPC drum phase adjustment
(Manual adjustment)
44-31
ADJ
10
registration
adjustment
(Print engine
section)
ADJ
10A
Image registration adjustment
(Main scanning direction, sub
scanning direction) (Auto
adjustment)
50-22
ADJ
10B
Image registration adjustment
(Main scanning direction)
(Manual adjustment)
50-20
ADJ
10C
Image registration adjustment
(Sub scanning direction)
(Manual adjustment)
50-21
SIM No Adjustment/setting item Default value
46-1 A – U 50
46-2 A – L 50
46-10 A – O 500
46-16 A – O 500
Display Content Set range
Default
value
HV Normal operation high-
density process control YES/
NO setting
Normal
(Inhibit: 1: NO)
Highlighted
(Allow: 0: YES)
Allow
HT Normal operation half-tone
process control YES/NO
setting
Allow
TC Transfer output correction
YES/NO setting
Allow
MD VG Membrane decrease grid
voltage correction YES/NO
setting
Allow
MD LD Membrane decrease laser
power voltage correction
YES/NO setting
Inhibit
MD EV Membrane decrease
environment grid voltage
correction YES/NO setting
Allow
MD DL Membrane decrease
discharge light quantity
correction YES/NO setting
Allow
MD DL EV Membrane decrease
environment discharge light
quantity correction YES/NO
setting
Inhibit
TN_HUM Toner density humidity
correction YES/NO setting
Allow
TN_AREA Toner density area correction
YES/NO setting
Allow
TN_LIFE Toner density life correction
YES/NO setting
Normal
(Inhibit: 1: NO)
Highlighted
(Allow: 0: YES)
Allow
TN_COV Toner density print rate
correction YES/NO setting
Allow
TN_PROCON Toner density process control
correction YES/NO setting
Allow
TN_ENV Toner density environment
correction YES/NO setting
Allow
TN_DRIP Toner density correction,
unconditional supply YES/
NO setting
Allow
TN_SPEND Toner compulsory
consumption mode YES/NO
setting
Allow
PHT 1Pixel half-tone process
control correction YES/NO
setting
Inhibit
AR_AUTO Auto resist adjustment YES/
NO setting
Allow
AR_ERROR Error check YES/NO setting
during auto resist adjustment
Allow
DM_PHASE Drum phase alignment YES/
NO setting
Allow
SENSITIVITY Toner density correction
YES/NO setting
Inhibit
PRT_HT Half tone process control
printer correction feedback
Enable/Disable setting
Allow
Job No Adjustment item
Simulation
to be used
ADJ 1 Developing doctor gap adjustment
ADJ 2 Developing roller main pole position adjustment
ADJ 4 High voltage
adjustment
ADJ
4A
Main charger grid voltage
adjustment
8-2
ADJ
4B
Developing bias voltage
adjustment
8-1
ADJ
4C
Transfer voltage adjustment 8-6
ADJ 12 Scan image focus adjustment (CCD unit position
adjustment)
Display Content Set range
Default
value
