Sharp MX-3570N

TROUBLE CODES
SHARP
62
L6
LSU Polygon Motor Trouble
10
Polygon motor trouble (LSU)
L8
Power / Electrical Trouble
01
Full wave signal detection trouble
02
Abnormal full wave signal error
20
MFP PWB & Mother board communication
trouble
PC
Personal Counter Trouble
--
Personal counter not installed
U1
Battery Trouble
01
Battery trouble.
U2
EEPROM / HDD / SSD / SRAM Trouble
00
MFP EEPROM read/write error
05
Account data error (HDD – MFP SRAM)
11
MFP PWB EEPROM check sum error.
30
Serial number discrepancy (MFP - PCU)
40
SSD card – system data partition trouble
41
HDD system storage data area error
42
Machine adjustment data (system storage
area) error
50
HDD user authentication data sum error
60
Watermark check error.
70
OCR dictionary check error
80
SCU PWB EEPROM read/write error.
81
SCU PWB EEPROM check sum error.
90
PCU PWB EEPROM read/write error.
91
PCU PWB EEPROM check sum error
U6
Desk / LCC Trouble
00
PCU PWB – Paper feed desk (tray3/tray4)
communication trouble
01
Desk paper feed tray 1 lift trouble
02
Desk paper feed tray 2 lift trouble
09
LCC lift motor trouble
10
Desk paper feed unit paper transport motor
trouble
20
LCC PWB - PCU PWB communication error
21
LCC paper transport motor trouble
22
LCC 24V power abnormality
50
Desk – Main unit combination trouble
51
LCC - Main unit mismatch trouble
52
LCC - Main unit combination trouble
54
LCC installation combination trouble
55
Desk installation combination trouble
U7
Vendor Mode Communication Trouble
50
Communication trouble between main unit
and vendor control
51
Vendor machine error
U9
Touch Panel Trouble
01
Touch panel trouble
UC
Scan ASIC Trouble
02
Scan ASIC IPD error
20
Scan ASIC DOCC error
