48 | Page
3 IF FLG ( IF FLG , )
When the flag is set,
• consider it as true and execute the next statement, else
execute the next line.
Ex: 10; IF FLG -,- GTO 15
11; A + 1 => A …
15; A * B => C
• Consider it true when FLG is set and execute from the
statement “GTO 15”.
• Consider it false when the FLG is reset and execute from
line 11;
Example:
execute statement: Y => LN (X
2
+
2
)
When X < 5 then skip next statement and instead, execute
the next line: Y => LN X
00; HLT X
01; 5 -,- LN (X * X + 1 + X * X)) => Y -,- GTO 3
02; LN X => Y
03; PRT Y
04; END END
