Sharp R-763IN

37
R-763 -
PARTS LIST
∆
OVEN PARTS
4-1 DOVN-A007URKO U Oven cavity 1 BP
4-2 LBNDKA107WRP1 U Capacitor holder 1 AD
4-3 PHOK-A002URF0 U Latch hook 1 AG
4-4 NFANJA001URE0 U Fan blade 1 AF
4-5 PDUC-A637WRF2 U Fan duct 1 AL
4-6 LANGFA155WRP7 U Chassis support 1 AF
4-7 PPACGA108WRE0 U Packing 1AC
4-8 PCUSUA017URE0 U Baseplate cushion 1 AC
4-9 MLEVPA001URF3 U Open lever 1 AE
4-10 NCPL-A042WRF1 U Coupling 1 AD
4-11 PCOVPA308WRE1 U Waveguide cover 1 AE
4-12 PFILWA042WRP0 U Lamp filter 1 AB
4-13 PDUC-A606WRF1 U Air intake duct 1 AK
4-15 PDUC-A514WRP0 U Air duct 1 AH
4-16 QTANNA006WRE0 J Earth plate 1 AB
4-17 PDUC-A612WRP0 U Exhaust duct 1 AQ
4-18 GCABDA063WRP0 U Back plate 1 AQ
4-20 PSPAGA001WRE0 U Vibration proof cushion 1 AA
4-21 LANGQA013URP0 U Rear air angle 1 AC
∆
R21 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 1 AA
R22 VRD-B12HF910J U Resistor 91 ohm 1/2W 1 AH
R30 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R31 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 1 AA
R32 VRD-B12EF103J U Resistor 10k ohm 1/4W 1 AA
R40 VRD-B12EF332J U Resistor 3.3k ohm 1/4W 1 AA
R50-51 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 2 AA
R52-53 VRD-B12EF104J U Resistor 100k ohm 1/4W 2 AA
R61-62 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 2 AA
RY1 RRLY-A080DRE0 U Relay (OJ-SH-124LM) 1 AG
RY2 RRLY-A093DRE0 U Relay (VRB18) 1 AM
RY3 RRLY-A092DRE0 U Relay (VRB18SP) 1 AP
SP1 RALM-A014DRE0 U Buzzer (PKM22EPT-THAI) 1 AG
SW50 RVR-BA018WRE0 U Encoder 1AH
T1 RTRNPA112DRE0 U Transformer 1 AP
VRS1 RH-VZA034DRE0 U Varistor (10G471K) 1 AD
ZD1 VHEHZ5C2///-1 U Zener diode (HZ5C2) 1 AB
ZD2 VHEHZ4A2///-1 U Zener diode (HZ4A2) 1 AB
ZD20 VHEHZ201///-1 U Zener diode (HZ20-1) 1 AB
3- 2-1 FW-VZA263DRZZ U 6-pin harness (CN-G) 1
3- 2-2 QSW-PA016DRE0 U Tact switch (SW1-SW7) 7 AB
3- 3 GMADIA005URF0 U Display window 1 AE
3- 4 HPNLCS019URT0 U Control panel frame 1 AW
3- 5 HPNLCK013URR0 U Jog panel 1 AQ
3- 6 JBTN-K028URR0 U Express/Defrost bottn 1 AE
3- 7 JBTN-K027URF0 U Stop/Start button 1 AE
3- 8 JKNBKK008URF0 U Rotary knob 1 AG
3- 9 XEPSD30P10XS0 U Screw; 3mm x 10mm 8 AA
CONTROL PANEL PARTS CONTINUED
REF. NO. PART NO. § DESCRIPTION Q’TY CODE
Note: The parts marked “*” are used in voltage more than 250V. The parts marked "∆" may cause undue microwave exposure
“§” MARK: SPARE PARTS-DELIVERY SECTION
