19
SJ-58L-T2
SJ-63L-T2
SJ-68L-T2
(3) Setting of Fan motor ass'y , Defrost thermo. ass'y and Fuse ass'y
After inserting, fix with vinyl tape.
60mm
Vinyl tape
(4) Inserting of pins
Aluminum
tape
Aluminum
tape
Turn up is lead wire
ATTENTION
cut
10 5mm
+
Tapping screw
Tapping
screw
E.V cover
E.V cover
sealer C
E
E
L-band C
L-band C
Defrost thermo.
assembly
Defrost thermo.
assembly
Set metal side below
F
F
Fuse assembly
E.V
cover
Fuse
ass’y
Lead E.V-
cover ass’y
Sec. F-F
Sec. E-E
Not come out of claw
Take out lead wire from
square hole to front, and
seal with E.V cover sealer C.
[FRONT SIDE]
more than
3.5mm
more than
3.5mm
Figure A-16
Figure A-18
123
456
789
F-thermostat 3
F-thermostat 4
Fuse 8
Fuse 7
Fan motor 1 , 2
Fan motor 9
(RED, inserted)
(BROWN, inserted)
(WHITE)
Defrost thermo. 5
Defrost thermo. 6
(PINK)
(BLUE)
(BLACK)
WIRE COLOR FOR FAN MOTOR
100-110V : WHITE
127V : YELLOW
220-240V : BLUE
Note Pins should be inserted surely,
and check by pulling it.
Figure A-17
