PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item ORDER NUMBER NAME SIZE Qty
1 D0000040301 Hex Socket- Head Screw M6xP1.0x30 6
10 A0001000600 Spindle R2059A 1
11 A0001000700 Pull Stud R1122D 1
12 C0088005300 Steel Bearing 70BNR10STYNDUELP4 2
13 A0001000800 Washer R0013C 2
14 A0001002700 Blot SNA4(90101) 6
15 C0088005100 Nut YSF M70*P2 1
16 A0001000900 Collar R1266A 1
17 A0001001000 Round Key R4180B 1
18 A0001001100 Nut R1314B 1
19 A0001001200 Sensor Ring R1152E 1
2 C0062000113 O-Ring ID29.7,W3.5 2
20 C0062000160 O-Ring ID107.67,W1.78 1
21 C0062000151 O-Ring ID4.8,W1.9 7
22 C0062000152 O-Ring ID134.4,W3.1 2
23 A0001002800 Collect BT40-45°(90003) 1
24 A0001002900 Shaft R8419A 1
25 C0062000153 O-Ring ID21.8,W2.4 2
26 A0001001500 Collar R5198A 1
27 A0001001600 Collar R5199A 1
28 A0001001700 Collar R1114A 1
29 C0062000154 O-Ring ID139.4,W3.1 4
3 D0000040201 Hex Socket- Head Screw M6xP1.0x20
30 C0062000155 O-Ring ID64.4,W3.1 1
31 C0088005400 Spring Pin φ5x16 2
32 A0001001800 Belt Pulley R1265B 1
