PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item NAME SIZE ORDERN UMBER Qty
1 Key way #40 2
2
Shaft
V10F02 1
3 Front – end cover V10E03 1
4 Jacketing KC141008-A 1
5 Collar KC1410005 1
6 Collar KC1410004 1
7 Spindle V10E01 1
8 Collar of inside KC141011C 1
9 Collar of outside KC141012C 1
10 Pull stud V10F17 1
11 Washer KC141025B 1
12 Washer V10A25 1
13 Collar V10F07 1
14 Belt pulley V10F13 1
15 磁性座
V10F15 1
16 Washer
KC141025F 1
17 Pull stud nut KCA141019H 1
18 中噴接頭
V10F29 1
19 Cylinder seat V10F30 1
20 Hex socket head screw M6*40 2
21 Hex socket head screw M8*28 6
22 Spray nozzle 6*6L 6
23 O-Ring G140
24 Bearing 70BNR10H
25 O-Ring G145
