PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
1 A0100000100 Main bracket 1
2 D0000050401 M8*40mm screw 2
3 D0012040051 Hexagonal nut 2
4 A0101000100 Adjusting spacer for belt 2
5 D0011040011 M6 safety washer 4
6 D0000040301 M6*30mm screw 4
7 C0153000100 Z axis left upper wipe 1
8 D0000030151 M5*15mm screw 24
9 D0004060401 Adjusting embedded bolt 6
10 C0153000200 Z axis right upper wiper 1
11 C0153000300 Z axis right under wiper 1
12 C0153000400 Z axis left under wiper 1
13 A0153000100 Left side guide plate 1
14 A0153000300 Embedded guide plate 2
15 A0153000200 Right side guide plate 1
16 D0010080021 M14 safety washer 14
17 D0000080601 M14*60mm screw 14
18 A0153000400 Embedded plate 1
19 C0062000111 Plastic oil hose (3/8*10p*6mm) 3
20 C0062000110 Ball valve 3
21 C0062000026 Straight connector (5.8mm*3.8PT) 1
22 C0061000001 Connector 1
