PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
1 A0200000100 Main bracket
1
2 D0000050501 M8*50mm screw
2
3 D0012050051 Hexagonal nut
4
4 A0101000100 Adjusting spacer for belt
2
5 D0011040901 M6 safety washer
10
6 D0000040251 M6*30mm screw
4
7 C0253000100 Z axis left upper wipe
2
8 D0000030151 M5*15mm screw
20
9 C0253000200 Z axis right wiper
2
10 D0000040201 M6*20mm screw
7
11 D0000050351 M6*35mm screw
2
12 D0000050301 M8*30mm screw
4
13 D0011050141 M8 safety washer
4
14 A0130100700 Adjustable spacer
2
15 A0253000100 Embedded plate
2
16 C0062000120 O - Ring
4
17 A0200000200 Embedded guide plate
2
18 A0200000300 Lift side guide plate
1
19 D0004070401 Embedded adjusting screw
9
20 D0011090301 M16 safety washer
12
21 D0000090501 M16*50mm screw
12
22 B0270000100 Embedded guide plate
4
23 C0002020081 Socket countersunk head screw
8
24 A0200000400 Right side guide plate
1
25 D0000040101 M6*10mm screw
4
26 B0270000200 Under cover of head
1
27 D0000040408 M6*40mm screw
2
28 C0062000110 Ball valve
3
29 A0200000500 Distributor block
1
