PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
1 A0140000100 Saddle base 1
2 D0018170013 Ball screw 2
3 A0152000100 M10 safety washer 1
4 D0011060021 M10*30mm screw 6
5 D0000060301 M5*20mm screw 6
6 D0000030201 X axis left stopper 4
7 C0151000100 Oil seal 4
8 C0050000100 X & Y axes motor adapter 4
9 A0150000100 Bearing 1
10 D0011070021 Outside bearing retainer 10
11 D0000070501 Bearing cap 10
12 C0088003300 M8 safety washer 4
13 C0050000200 M8*35mm screw 6
14 A0150000500 Inside bearing retainer 1
15 A0150000400 Lock nut 2
16 D0011050021 M12 safety washer 12
17 D0000050351 Tapping pin with internal thread(1~48”) 12
18 A0150000600 M12*50mm screw 2
19 C0050000300 X & Y axes motor adapter cover 2
20 B0150000100 M5 washer 1
21 D0010030011 M5*15mm screw 4
22 D0000030151 Axis bearing case 4
23 A0150000200 Outside bearing retainer 1
24 A0150000700 X direction cable chain bracket 1
25 A0140000200 M6 washer 12
26 A0140000300 M6*15mm screw 12
27 A0140000400 Cable chain 12
