150
PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
1 A0220000100 Saddle base
1
2 A0251000100 Ball screw
1
3 D0011070021 M12 safety washer
11
4 D0000070301 M12*30mm screw
5
5 C0062000119 Oil seal
4
6 B0270000300 motor adapter cover
1
7 D0010040011 M6 safety washer
11
8 D0000040151 M6*15mm screw
8
9 D0000080601 M14*60mm screw
10
10 C0088003300 Tapping pin with internal thread(1~48”)
6
11 D0011080051 M14 safety washer
10
12 A0250000100 motor adapter
1
13 C0050000400 Bearing
6
14 A0250000400 Bearing cap
2
15 D0011050021 M8 safety washer
16
16 D0000050301 M8*30mm screw
12
17 A0250000500 Spacer
2
18 A0250000200 Bearing case
1
19 D0004070401 Adjustable embedded screw
14
20 A0230000100 Table left rear pressure plate
1
21 A0230000200 Table left front pressure plate
1
22 A0230000300 Table right front pressure plate
1
23 C0002020081 Socket Countersunk Head Screw
24
24 B0251000100 Embedded cover
12
25 A0230000400 Table right rear pressure plate
1
26 D0000090601 M16*60mm screw
32
27 D0011040021 M16 safety washer
32
28 A0230000500 Table plate embedded
4
29 D0000070501 M12*50mm screw
6
30 A0251000200 X axis nut case
1
