38
PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Name Item Name
A Left front embedded pressure plate I Right front embedded pressure plate
B Front left-right reference surface J Front right-right reference surface
C Front left-left reference surface K Front right-left reference surface
D Left front guide way surface L Right front guide way surface
E Left rear guide way surface M Right rear guide way surface
F Rear left-left reference surface N Rear right-left reference surface
G Rear left-right reference surface O Rear right-right reference surface
H Left front embedded pressure plate P Right front embedded pressure plate
Number Model Name Quantity
1. PKD6 3-way pipe 2
2. PB6 Pipe 8
3. PA6 Pipe cape 8
4. HBL-4 Volume-based distributor 1
5. HBL-5 Volume-based distributor 2
6. PAN4 Nut 17
7. PB4 Pipe 34
8. PA4 Pipe cape 17
9. PH4-1 Flat and straight-angle connector 17
10. PH601 Straight-angle connector 2
11. HBL-3 Volume-based distributor 1
12. PQ101 Connector 2
13 PG01 Sealing plug 1
