Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
77
VE-CG30U
VE-CG40U
SC701 QSOCN1007REN1Y J Socket, 10Pin AD
SC702 QSOCN1098TAZZY J Socket, 10Pin AE
SC801 QSOCN1898TAZZY J Socket, 18Pin AE
SC1001 QSOCN1672TAZZY J Socket, 16Pin AD
SC1002 QSOCN0672TAZZY J Socket, 6PIn AC
SC3001 QSOCN1507REN1Y J Socket, 15Pin AD
TP1 QLUGZ0110TAZZY J Lug AA
TP2 QLUGZ0110TAZZY J Lug AA
TP3 QLUGZ0110TAZZY J Lug AA
DUNTKB358PM00(VE-CG40U)
DUNTKB358PM01(VE-CG30U)
OPERATION PWB UNIT
CAPACITORS
C1701 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
C1702 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
C1703 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
C1704 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
C1705 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
C1706 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
C1707 VCKYCZ1HB102KY J 1000p 50V Ceramic AB
RESISTORS
R1701 VRS-TV1JD563JY J 56k 1/16W Metal Oxide AA
R1702 VRS-TV1JD563JY J 56k 1/16W Metal Oxide AA
R1703 VRS-TV1JD330JY J 33 1/16W Metal Oxide AA
R1704 VRS-TV1JD330JY J 33 1/16W Metal Oxide AA
R1705 VRS-TV1JD330JY J 33 1/16W Metal Oxide AA
R1706 VRS-TV1JD330JY J 33 1/16W Metal Oxide AA
R1707 VRS-TV1JD330JY J 33 1/16W Metal Oxide AA
R1708 VRS-TV1JD330JY J 33 1/16W Metal Oxide AA
R1709 VRS-TV1JD330JY J 33 1/16W Metal Oxide AA
R1710 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
(CG40U)
R1711 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
(CG40U)
SWITCHES
S1701 QSW-K0031TAZZY J Switch AC
S1702 QSW-K0031TAZZY J Switch AC
S1703 QSW-K0031TAZZY J Switch AC
S1704 QSW-K0031TAZZY J Switch AC
S1705 QSW-K0031TAZZY J Switch AC
S1706 QSW-K0031TAZZY J Switch AC
S1707 QSW-K0031TAZZY J Switch AC
S1708 QSW-K0031TAZZY J Switch AC
S1709 QSW-K0031TAZZY J Switch AC
MISCELLANEOUS PARTS
P1701 QPLGN0276TAZZY J Plug, 2Pin(CG40U) AD
SC1701 QSOCN1025TAN1Y J Socket, 10Pin AD
DUNTKB359PM00(VE-CG40U)
DUNTKB359PM01(VE-CG30U)
JACK PWB UNIT
DIODE
D4401 VHDDA221///-1Y J DA221 AB
COILS
S4403 RCiLFA001WJZZY J Coil, CiLFA001WJ AD
S4404 RCiLFA001WJZZY J Coil, CiLFA001WJ AD
CAPACITORS
C4401 VCCCCZ1HH101JY J 100p 50V Ceramic AB
C4402 VCCCCZ1HH101JY J 100p 50V Ceramic AB
C4403 VCKYCY1HB471KY J 470p 50V Ceramic AA
R2901 VRS-CZ1JF471JY J 470 1/16W Metal Oxide AA
R2902 VRS-CZ1JF222JY J 2.2k 1/16W Metal Oxide AA
R2903 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R2904 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R3901 VRS-CZ1JF100JY J 10 1/16W Metal Oxide AA
R3902 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R3903 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R3904 VRS-CZ1JF272JY J 2.7k 1/16W Metal Oxide AA
R3908 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
(CG40U)
R4901 VRS-CZ1JF100JY J 10 1/16W Metal Oxide AA
R4902 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R4903 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R4904 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R4906 VRS-CZ1JF272JY J 2.7k 1/16W Metal Oxide AA
R4908 VRS-CZ1JF272JY J 2.7k 1/16W Metal Oxide AA
R5901 VRS-CZ1JF100JY J 10 1/16W Metal Oxide AA
R5902 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R5903 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R5904 VRS-CZ1JF153JY J 15k 1/16W Metal Oxide AA
R5905 VRS-CZ1JF683JY J 68k 1/16W Metal Oxide AA
R5906 VRS-CZ1JF222JY J 2.2k 1/16W Metal Oxide AA
R5907 VRS-CZ1JF223JY J 22k 1/16W Metal Oxide AA
R5908 VRS-CZ1JF683JY J 68k 1/16W Metal Oxide AA
R5909 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R5910 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R5911 VRS-CZ1JF102JY J 1k 1/16W Metal Oxide AA
R5912 VRS-CZ1JF183DY J 18k 1/16W Metal Oxide AA
R5913 VRS-CZ1JF242JY J 2.4k 1/16W Metal Oxide AA
R5914 VRS-CZ1JF332DY J 3.3k 1/16W Metal Oxide AA
R6901 VRS-CZ1JF100JY J 10 1/16W Metal Oxide AA
R6902 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R7901 VRS-CZ1JF332JY J 3.3k 1/16W Metal Oxide AA
R7902 VRS-CZ1JF222JY J 2.2k 1/16W Metal Oxide AA
R8901 VRS-CZ1JF270DY J 27 1/16W Metal Oxide AA
R8902 VRS-CZ1JF473DY J 47k 1/16W Metal Oxide AA
R8903 VRS-CZ1JF103DY J 10k 1/16W Metal Oxide AA
R8904 VRS-CZ1JF103JY J 10k 1/16W Metal Oxide AA
R8905 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R8906 VRS-CZ1JF100JY J 10 1/16W Metal Oxide AA
R9902 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9903 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9904 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
(CG40U)
R9905 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9906 VRS-CZ1JF000JY J 0 1/16W Metal Oxide AA
R9907 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
BALUNES
FB701 RBLN-0110TAZZY J Balun, BLN-0110TA AB
FB702 RBLN-0110TAZZY J Balun, BLN-0110TA AB
FB1601 RBLN-0081TAZZY J Balun, BLN-0081TA AA
(CG40U)
FB1602 RBLN-0081TAZZY J Balun, BLN-0081TA AA
(CG40U)
FB2901 RBLN-0119TAZZY J Balun, BLN-0119TA AC
FB2902 RBLN-0119TAZZY J Balun, BLN-0119TA AC
FB8901 RBLN-0102TAZZY J Balun, BLN-0102TA AB
FB8902 RBLN-0102TAZZY J Balun, BLN-0102TA AB
SWITCHES
S201 QSW-MA001WJZZY J Switch, Card Door SW AD
S204 QSW-K0031TAZZY J Switch, TELE AC
S205 QSW-K0031TAZZY J Switch, WIDE AC
MISCELLANEOUS PARTS
å F2901 QFS-LA008WJZZY J Fuse, 1.25A AC
P1602 QPLGN0274TAZZY J Plug, 2Pin(CG40U) AC
P2901 QPLGN0458REZZY J Plug, 4Pin AD
P2902 QPLGN0463TAZZY J Plug, 4Pin AC
SC201 QSOCZA035WJZZY J Socket, 12Pin AK
SC202 QSOCN0825TAN1Y J Socket, 8Pin AD
SC401 QSOCN1007REN1Y J Socket, 10Pin AD
DUNTKB356QA00(VE-CG40U)
DUNTKB357QA00(VE-CG30U)
MAIN PWB UNIT(Continued)
