CONNECTIONS FOR SERVICING
Use the following extension cables in servicing the VCR unit taken out of the set.
Extension cables:
Part codes
QCNW-3778CEZZ,
QCNW-3780CEZZ
l
Connecting the extension cables
(1)
Between
AB
(TV unit) and
JA
(AV
jack):
Connect the cable
QCNW-3778CEZZ
between the
AB
plug and the
AB
socket.
(2)
Between AL (TV unit) and LA (LED unit):
Connect the cable
QCNW-3780CEZZ
between the AL plug and the AL socket.
Extension cable: QCNW-3780CEZZ
Extension
cable: QCNW-3778CEZZ
5.
Remove the CRT
PWB,
degaussing
coil connector
G,
and front power switch remote control
PWB.
Place
the main
PWB
upright.
6.
Reconnect the CRT
PWB.
Put the main
PWB
and the VCR unit together as shown below. Keep the front
power switch remote control
PWB,
speakers and
degaussing
coil connector G off position.
Only for
~oUnd0
*
VT-51 18X
,
\
‘LINE FILTER PWB
(Only for VT-341 8X)
/
Power
SW+I/C
PWB
DA
To Next Page
