Parameter address and parameter
description
parameter description
3000H Operating speed
3001H Setting speed
3002H Busbar voltage
3003H Output voltage
3004H Output current
3005H Rotate speed of the operation
3006H Output power
3007H Output torque
3008H Given value of PID
3009H Feedback of PID
300AH Indicating state of terminal input
300BH Indicating state of terminal output
300CH Value of analog AI1
300DH Value of analog AI2
300EH Value of analog AI3
300FH Value of analog AI4
3010H
Impulse frequency with high speed（HDI1）
3011H
Impulse frequency with high speed（HDI2）
3012H Multistep speed and current stage of PLC
3013H Length value
3014H Input value of external counter
3015H Torque direction (0: forward direction, 1:
reverse direction)
3016H Device code
The set value is the percentage of relative value: 10000 corresponding with
100.00% and -10000 corresponding with -100.00%.
Data corresponding with the frequency dimension; and this percentage is the
percentage corresponding with maximum frequency （ P0-10 ） ; Data
corresponding with the torque dimension, the percentage is P2-10(setting for
upper limiting number of the torque ).
Input the control command into AC frequency vector inverter (only for
writing)
Address of command word Command function
1000H
0001H: forward rotation
0002H: reverse rotation
0003H: normal inching turning
0004H: point turning of inversion
0005H: halt
