Chapter 4 Operation keyboard
Chapter 4
37
4-4-2.
Form of secondary menu
P
0
0
.
0
0
Function code area
Group number in the area
separator
Index in the group
Chart4-3 Form of secondary menu
Data display or setting form of secondary menu
Decimal display/setting:
Sign can be displayed or set by data bits 1~5 is 0-9.
4-4-3. Form of three-level menu
5
0
.
0
1
Data bit
1
Decimal point
Chart4-4 Form of three-level menu
Data bit 2
Data bit 3
Data bit
4
4-4-4.
Common display symbol of LED
Besides function code, the first-level menu, secondary menu and three-level menu,
the operation panel will show some prompting character; and see following table
for detail:
Prompt
Implication
Prompt
Implication
PT200
The AC frequency vector inverters instantly
show PT200 to represent PT200 product
after electrifying
E.PHI Default phase at the input side
E.oUP U-phase protection of inverter unit E.PHo Default phase at the output side
E.oUP V-phase protection of inverter unit E.oH1
Overheating of rectifier
module
E.oUP W-phase protection of inverter unit E.oH2 Overheating of inverter module
E.oC1 Over current of acceleration E.SET External fault
E.oC2 Over current of deceleration E.CE Communication fault
E.oC3 Over current of constant speed E.ItE Fault of current detection
E.oU1 Overvoltage of acceleration E.tE Fault for self-study of motor
E.oU2 Overvoltage of deceleration E.EEP Operation fault of EEPROM
E.oU3 Over current of constant speed E.PId
Break-line fault for feedback of
PID
