Chapter 6 inverter of function parameter
Chapter 6
84
No. Code
Describing LED/OLED
Keyboard display
Setting range
Factory
setting
Change
77
P05.07
Demarcation frequency
for low and high
frequency of restricting
vibration
0.00Hz ～ P01.07(maximum
frequency)
12.50Hz
◇
P05.07 is the cut-off point for function code: P05.04 and P05.05.
78
P05.08 Restrict vibration
0: restricting vibration is valid
1: restricting vibration is
invalid
1
◇
0: Restricting vibration is valid
1: Restricting vibration is invalid. Function of restricting vibration is for VF control; common motor
regularly has current shock for the no-load or light load operation, which can cause the abnormal operation
of the motor; what is worse, it can also cause the over current of AC frequency vector inverter. When
P05.08=0, enabling restricts the vibration; and AC frequency vector inverter will control the vibration
of the motor appeared based on the parameter in P05.04～P05.07 function group.
79
P05.09 V/F frequency point 1 0.00HZ～P05.11 0.00HZ □
80
P05.10 V/F voltage point 1 0.0～100.0% 0.0% □
81
P05.11 V/F frequency point 2
P5.09～P05.13
0.00HZ
□
82
P05.12 V/F voltage point 2
0.0～100.0%
0.0%
□
83
P05.13 V/F frequency point 3 P05.11～P03.02 0.00HZ
□
84
P05.14 V/F voltage point 3 0.0～100.0% 0.0%
□
85
P05.15
Selection for energy-
saving operation
0: Failure to actuate
1: Automatic energy-saving
operation
0 □
During the process of no-load or light load operation, the motor can properly adjust output voltage to
reach the aim of automatic energy-saving via detecting the load current.
Notice: this function is particularly effective for load of fan and pump.
The function code in this group is only valid for V/F control (P01.00＝0).
6-2-7.P06 group input terminal group
No. Code
Describing LED/OLED
Keyboard display
Setting range
Factory setting
Change
86
P06.00
Function selection of DI1
terminal
0: No function
1: Forward running
2: Reverse run
3: Three-wire control
operation control
4: Forward JOG
5: Reverse JOG
6: Random parking
7: Fault resetting
8: Input of external fault
1
□
87
P06.01
Function selection of DI2
terminal
2
□
88
P06.02
Function selection of DI3
terminal
4
□
89
P06.03
Function selection of DI4
terminal
0
□
